Introduction
2
MVP-5100/5150 5.2" Modero Viewpoint Touch Panels
Product Specifications
MVP-5150 Product Specifications
Dimensions: 4 3/4" x 7 9/16" x 13/16" (120.7 mm x 191.8 mm x 20.3 mm)
Weight: • 1.25 lbs (0.57 kg)
Enclosure: Matte black plastic.
Power Requirements
(Without Charging):
FG5966-07, Panel with battery fully charged or with no battery:
• Constant current draw: 0.3 A @ 12 VDC
• Startup current draw: 0.4 A @ 12 VDC
FG5966-09, Panel with battery fully charged or with no battery:
• Constant current draw: 0.29 A @ 12 VDC
• Startup current draw: 0.37 A @ 12 VDC
Power Requirements
(While Charging):
FG5966-07, Panel while charging battery:
• Constant current draw: 1.1 A @ 12 VDC
• Startup current draw: 1.3 A @ 12 VDC
FG5966-09, Panel while charging battery:
• Constant current draw: 1.04 A @ 12 VDC
• Startup current draw: 1.07 A @ 12 VDC
Minimum Power Supply
Required:
• PS3.0 Power Supply (FG423-30) - both 120 VAC and 240 VAC models are
shipped with this power supply
Power Modes: • AWAKE: All necessary modules are powered up and device remains online
with the NetLinx Master.
• SLEEP: Only the backlight will be turned off after the user selectable time of
inactivity has elapsed. Panel resumes the ON mode in ~ 1 second upon a
momentary press of the touchscreen.
• STANDBY: Power to all components other than the touch screen is turned off
after the user selectable time of inactivity has elapsed. Device will turn back
on by touching the screen. Re-acquiring an AP connection may require up to
10 seconds.
• SHUTDOWN: Power to all peripherals and components is turned off. The
system remains in this mode until either it is rebooted or the battery is
completely drained.
Battery Duration: FG5966-07:
• Eight hours of normal use, in a combination of On, Sleep, and Shutdown
Modes.
• Five hours of continuous use (continuous On state).
FG5966-09
• 8.5 hours of normal use, in a combination of On, Sleep, and Shutdown
Modes.
• 5.1 hours of continuous use (continuous On state).
Certifications: • FCC Part 15 Class B
•CE
• IEC/EN-60950
•RoHS
• Japan Approved
• Lithium polymer microbattery: UN/IATA
Memory:
• 128 MB Mobile DDRAM (upgrade not available)
• 256 MB NAND Flash (upgrade not available)
Panel LCD Parameters:
Screen size: • FG5966-07: 5.2” (13.21 cm)
• FG5966-09: 5.0” (12.59 cm)
Screen resolution (WH): 800 x 480 pixels (HV) @ 60 Hz frame frequency
