Introduction
7
MVP-5100/5150 5.2" Modero Viewpoint Touch Panels
Memory
The MVP-5100 and MVP-5150 come with 128MB of Mobile DDRAM memory and 256 MB NAND
Flash memory. Neither memory may be upgraded.
USB Connector Location
With the unit facing you, the mini-USB port (for programming and downloading firmware using the
AMX-provided adaptor cable) and the DC power port are located on the lower left side of the device
MVP-5100 Specifications (FG5966-08) (Cont.)
Panel LCD Parameters: • Size: 5.2" (13.21 cm)
• Type: WVGA
• Aspect ratio: 16 x 9
• Brightness (luminance): 300 cd/m
2
• Channel transparency: 8-bit Alpha blending
• Contrast ratio: 20:1
• Display colors: 262,144 colors (18-bit color depth)
• Dot/pixel pitch: 0.23 mm
• Panel type: TFT Color Active-Matrix
• Screen resolution: 800 x 480 pixels (HV) @ 60 Hz frame frequency
• Viewing angles:
Vertical: + 40° (up from center) and - 80° (down from center)
Horizontal: + 60° (left from center) and - 60° (right from center)
External Components
Connector: 5-pin Mini-USB connector used for programming, firmware updates, and touch
panel file transfer between the PC and the target panel.
Note: When connecting the panel to PC using a CC-USB (or compatible)
cable, be sure to power the panel On before attempting to connect the USB
cable from the PC to the mini-USB port on the panel.
DC power port: 2.5 mm port to power the panel away from a Charging Station.
Speaker: •4 Ohm
• 2 Watts 300Hz cutoff frequency
• NOTE: Speaker is only used for feedback beeps, and will not transmit
standard audio.
IR Emitters: Transmit IR over 20 feet (6.10 m) from the panel.
• IR emitters on G4 panels share the device address number of the panel.
• Transmits AMX fixed frequencies at 38KHz and 455KHz and 8 user-
programmable frequencies from 20KHz to 1.5MHz
Operating/Storage
Environment
• Operating Temperature: 0° C (32° F) to 40° C (104° F)
• Operating Humidity: 5% - 85% RH
• Storage Temperature: -20° C (-4° F) to 60° C (140° F)
• Storage Humidity: 5% - 85% RH
Included Accessories: • MVP-5100 Installation Guide (93-5966-01)
• PS3.0 Power Supply (FG423-30)
Other AMX Equipment: • MVP-TCS-52: Table Charging Station (FG5966-1X)
• MVP-WCS-52: Wall Charging Station (FG5966-1X)
• MVP-BP-51-NK: Replacement MVP-5100 Battery (FG-5966-25)
• MVP-BP-52: Battery Replacement Kit (FG5966-20)
• MVP-STYLUS-52: Stylus, Pack of 3 (FG5966-30-xx)
• CC-USB: USB Programming Cable (FG10-5965)
• MVP-HP USB 1/8" Adapter (FG5966-23)
