MVP-5100/5150 5.2" Modero Viewpoint Touch Panels
Manually entering the SSID information into the appropriate fields by following steps 7
through 9.
3. From within the Information/Configuration section, press the Simple button to open the Wireless
Security: Simple Mode popup window (FIG. 18). An Open security method does not utilize any
encryption methodology, but does require that an alpha-numeric SSID be entered. This method
sends out network packets as unencrypted text.
4. Press the red SSID field to display an on-screen Network Name (SSID) keyboard.
5. In this keyboard, enter the SSID name used on the target Access Point (case sensitive).
The card should be given the SSID used by the target AP. If this field is left blank, the unit will
attempt to connect to the first available AP.
One of the most common problems associated with connection to an AP involves an incorrect
SSID. Make sure to maintain the same case when entering the SSID information. ABC is not
the same as Abc.
6. Click Done when complete.
7. Press the Save button to incorporate the new information into the device and begin the
communication process.
8. Verify the proper configuration in the fields in the IP Settings section. Refer to Step 1: Configure the
Device’s Wireless IP Settings (MVP-5150 Only) section on page 26 for detailed information.
FIG. 17 Site Survey of available APS (Unsecured AP shown selected)
FIG. 18 Wireless Security: Simple Mode popup window
Connecting to the
AP begins the
communication
