Setup Pages
46
MVP-5100/5150 5.2" Modero Viewpoint Touch Panels
Project Information Page (Cont.)
Sales Order: Displays the sales order information.
Purchase Order: Displays the purchase order information.
AMX IR 38K Assigned
Port:
Displays the AMX 38 kHz IR channel port used by the IR Emitter on the panel.
• This information is specified in TPD4 (Project Properties > IR Emitters &
Receivers tab).
• For example, if you set the AMX IR 38K Port to 7 and then put a button on the
panel with a channel code of
5 and a port of 7, it will trigger the IR code in slot 5
of the AMX IR 38K Port.
IR User Def1 Port: Displays the primary channel port used by the IR receiver on the panel.
IR User Def2 Port: Displays the secondary channel port used by the IR receiver on the panel
Build Number: Displays the build number information of the TPD4 software used to create the
project file.
Creation Date: Displays the project creation date.
Revision Date: Displays the last revision date for the project.
Last Save Date: Displays the last date the project was saved.
Blink Rate: Displays the feedback blink rate, in 10-second increments.
Job Comments: Displays any comments associated to the job (from the TPD4 project file).
Cradle Sensor Port: Displays the port used by the charging cradle sensor.
Cradle Sensor Channel: Displays the channel used to broadcast the charging cradle sensor status.
IR receivers and transmitters on G4 panels share the device address number of the
panel.
