Protected Setup Pages
74
MVP-5100/5150 5.2" Modero Viewpoint Touch Panels
Refer to the EAP Authentication section on page 168 and the Using the Site Survey Tool section on
page 28 for further details on these security options.
EAP-TTLS Settings (Cont.)
Certificate Authority: When pressed, the panel displays an on-screen Certificate Authority (CA)
File Location keyboard which allows you to enter the name of the certificate
authority file which is used to validate the server certificate. This field is
optional.
If a server certificate is used, it should first be downloaded into the panel and
the
Certificate Authority field should then be set to the name of that certificate
file. No file path should be used for this setting as all certificates are stored in
a specific directory that the user cannot control or change.
Use the on-screen keyboard’s Clear button to completely erase any
previously stored network path information.
Inner Authentication Type: When pressed, this field cycles through the choices of available Inner
Authentication mechanisms supported include:
• EAP-MSCHAPv2
• EAP-GTC
• EAP-OTP
• EAP-MD5
• MSCHAPv2
• MSCHAP
•PAP
• CHAP
Cancel/Save: • Cancel - discard changes and return to the previous page.
• Save - store the new security information, apply changes, and return to the
previous page.
