Specifications

Overview
5
Vision
2
Operation/Reference Guide
WMV Appliance
The following table lists the specifications for the Vision
2
WMV appliances:
Vision
2
WMV Appliance Specifications
Processor: Quad Core Xeon X3323 Processor2x3MB Cache, 2.5GHz, 1333 MHz FSB
Memory: 2GB 667MHz (2x1GB), single ranked DIMMs
Storage: 2 250GB 7.2K RPM serial ATA 3Gbps 3.5-in cabled hard drives
Power: Single 400W power supply
Front Panel Components:
USB ports 2 USB 2.0 ports for mouse, keyboard, or external peripheral devices
Video connector 1 15-pin (female) video connector for connecting a video output device such as
a PC monitor
DVD-ROM 8X DVD-ROM drive
Rear Panel Components:
Serial connector 1 9-pin (male) serial connector
Video connector 1 15-pin (female) video connector for connecting a video output device such as
a PC monitor
USB ports 2 USB 2.0 ports for mouse, keyboard, or external peripheral devices
LAN connectors 2 RJ-45 LAN ports for connecting to a network router (10/100/1000 Ethernet)
WMV Video connector 2 15-pin (male) video connectors for WMV source (WMV appliance only)
Rack Mount Sliding Ready™ rails with Cable Management arm
Operating Environment: • Operating Temperature: 10º C to 35º C (50º F to 95º F)
• Storage Temperature: -40º C to 65º C (-40º F to 149º F)
• Operating Relative Humidity (non-condensing twmax=29º C): 20% to 80%
non-condensing
• Maximum humidity gradient: 10% per hour, operational and non-operational
conditions
• Storage Relative Humidity: 5% to 95% non-condensing (twmax=38º C)
Dimensions (HWD): 1 11/16" (4.235cm) H x 16 3/4" (42.63cm) W x 26" (66.04cm) D
Weight: Rack Weight 29.66 lbs (13.45 kg)
