Specifications

Overview
8
Vision
2
Operation/Reference Guide
MPEG Reflector Appliance
The following table lists the specifications for the V2-MPEG-REFL MPEG Reflector Appliance:
V2-MPEG-REFL Appliance Specifications
Processor: One Quad-Core Intel
®
Xeon
®
3420 series processor
Memory: 2GB Memory (2x1GB), 1066MHz Single Ranked UDIMM
Storage: 250GB 7.2k RPM Serial ATA 3Gbps 3.5-in Cabled Hard Drive-Entry
Power: Single cabled power supply (250W)
Front Panel Components:
USB ports 2 USB 2.0 ports for mouse, keyboard, or external peripheral devices
Video connector 1 15-pin (female) video connector for connecting a video output device such as
a PC monitor
Rear Panel Components:
Serial connector 1 9-pin (male) serial connector
Video connector 1 15-pin (female) video connector for connecting a video output device such as
a PC monitor
USB ports 2 USB 2.0 ports for mouse, keyboard, or external peripheral devices
LAN connectors 2 RJ-45 LAN ports for connecting to a network router (10/100/1000 Ethernet)
Rack Mount Sliding Ready™ rails with Cable Management arm
Dimensions (HWD): 1 11/16" (4.24cm) x 17 1/8" (43.43cm) x 15 1/2" (39.37cm)
Weight: 17.76 lbs (8.058 kg)
Operating Environment: • Operating Temperature: 10º C to 35º C (50º F to 95º F)
• Storage Temperature: -40º C to 65º C (-40º F to 149º F)
• Operating Relative Humidity (non-condensing twmax=29º C): 20% to 80%
non-condensing
• Maximum humidity gradient: 10% per hour, operational and non-operational
conditions
• Storage Relative Humidity: 5% to 95% non-condensing (twmax=38º C)
