Dealer Demo System Specifications
The following table lists the specifications for the V2-DLR-DEMO-SFF Dealer Demo Server:
V2-DLR-DEMO-SFF Dealer Demo Server Specifications
Power: 100-240VAC, 1.5A, 50/60Hz
90W (20V, 4.5A) AC Adapter
Enclosure: SECC with black matte finish
Front Panel Components:
Status Blue LED indicates power status
Power Switch Turns power on/off.
USB ports 2 Type-B USB 2.0 ports for connecting USB mouse and keyboard
Rear Panel Components:
Power connector 90W (20V, 4.5A) AC Adapter
Input Voltage AC 100-240V
Note: Isolate IT Power System Connection.
USB ports 4 Type-B USB 2.0 ports
LAN port RJ-45 LAN port provides Gigabit Ethernet communication
Audio Out Provides stereo audio output
Note: The Audio in (blue) and Microphone (red) connectors are not used.
Serial Port Provides serial control over devices which support RS-232 commands.
HDMI Video Out Provides HDMI video output to the display, via an HDMI cable.
VGA Video Out Provides VGA video output to the display
e-SATA Reserved for future use
Dimensions (HWD): 6 9/16" (16.6 cm) H x 1 7/8" (4.8 cm) W x 6 7/16" (16.4cm) D
Weight: 2.85 lbs (1.3 kg)
Operating Environment: • Operating Temperature: 0º C to 50º C (32º F to 122º F)
• Storage Temperature: -30º C to 60º C (-22º F to 140º F)
• Relative Humidity: 90% RH (45º C non-condensing)
