MPEG Configuration
The MPEG reflector can receive both unicast or multicast streams and output both unicast or multicast
streams. When you select the Configure Reflector from the MPEG Reflector Service Menu the following page
appears (FIG. 74).
The following options appear on the Reflector service configuration page:
FIG. 74 Configure Vision
2
MPEG Reflector Service
Reflector MPEG Service Options
Service Enable This enables the service and will begin multicasting if appropriate.
Note: You cannot edit any of the other settings while the service is enabled.
Channel Name The name of the service as it appears in the playlists.
Source
Type Click the appropriate option button to indicate the source type. You can choose
from Local Vision2 Channel or External Source.
V2 Channels The options menu provides a list of all the Producer channels in the system.
This option is only available if you select Local Vision2 Channel as the source
type.
URL Use the provided field to enter the URL containing an MPEG-2 or H.264 video.
This option is only available if you select External Source as the source type.
Destination
Stream type Click the appropriate option button to indicate the stream type. You should
select Multicast if you are streaming over an Intranet. Select Unicast for an
Internet stream.
Multicast options These options are only available if you select Multicast as the Stream type.
Address The multicast address for this channel. This option is pre-configured and
cannot be changed.
Port The multicast port for this channel. This option is pre-configured and cannot be
changed.
TTL The multicast TTL for this channel. This option is pre-configured and cannot be
changed.
