Evaluation Board User Guide UG-003
Rev. A | Page 27 of 40
ORDERING INFORMATION
BILL OF MATERIALS
Table 3. AD9650 Family BOM
Item Qty
Reference
Designator Description Value Manufacturer/Part No.
1
1
0 C108, C109 Capacitor, ceramic, X7R, 0402 0.01 μF, 25 V Panasonic/ECJ-0EB1E103K
2
1
0 C110 Capacitor, ceramic, X7R, 0402 2.2 nF, ±10%, 25 V Phycomp (Yageo)/0402R222K8B20D
3
1
0 C111, C113, C519 Capacitor, ceramic, C0G, 0402 100 pF, 50 V, 5% Murata/GRM1555C1H101JD01D
4
1
0 C112 Capacitor, ceramic, X7R, 0402 1500 pF, 50 V Panasonic/ECJ-0EB1H152K
5
1
0 C137, C140
6A 2 C408, C508 Capacitor, ceramic, C0G, 0402 2.2pF, 50 V Murata/GRM1555C1H2R2CZ01D
6B 4 C409, C411, C509, C511 Capacitor, ceramic, C0G, 0402 15 pF, 50 V, 5% Murata/GRM1555C1H150JZ01D
6C 2 C410, C510 Capacitor, ceramic, C0G, 0402 5.0 pF, 50 V Murata/GRM1555C1H5R0CZ01D
7
1
0
C201, C202, C412,
C413, C414, C415,
C416, C421, C427,
C512, C513, C521,
C522, C610, C703,
C704, C708, C709
8
1
0 C422, C423 Capacitor, ceramic, X7R, 0402 0.1 μF, 16 V Panasonic/ECJ-0EX1C104K
9
1
0 C424 Capacitor, ceramic, SMD, 0402 1200 pF, 25 V Panasonic/ECJ-0EB1E122K
10
1
0 C425 Capacitor, ceramic CL05C2R7CBNC Samsung/CL05C2R7CBNC
11
1
0 C517, C518 Capacitor, ceramic, C0G, 0402 20 pF, 50 V, 5%, Murata/GRM1555C1H200JZ01D
12
1
0 C520 Capacitor, ceramic, SMD, 0402 ECU-E1E102KBQ Panasonic/ECU-E1E102KBQ
13
1
0
E104, E106, E108,
E116, E117, E118,
E119
Capacitor, ceramic 0402CG390J9B200
Phycomp
(Yageo)/0402CG390J9B200
14
1
0
J401, J502, J601, J702,
J703, J704
Bead core, 0805, SMD 4 A, 100 MHz Panasonic/EXC-ML20A390U
15
1
0 JP102, JP104
SMA straight, edge-mount
stack
50 Ω Samtec/SMA-J-P-X-ST-EM1
16
1
0 L101, L102 Inductors
17
1
0 L401, L502 Fixed inductors FDV0630-2R2M TOKO/FDV0630-2R2M
18
1
0 L405, L505 Resistor, 0603, SMD 0.0 Ω, 1/10 W Panasonic/ERJ-3GEY0R00V
19
1
0 L406, L407 Ceramic chip inductor 0603CS-R10XGLU Coilcraft/0603CS-R10XGLU
20
1
0 L408, L409, L410, L411 Chip inductor 0603LS-102XGLB Coilcraft/0603LS-102XGLB
21
1
0 L508, L509 Ceramic chip inductor 0603CS-R27XGLW Coilcraft/0603CS-R27XGLW
22
1
0 L510, L520 Chip inductor 0603CS-15NXGLU Coilcraft/0603CS-15NXGLU
23
1
0 L521, L522 Chip inductor 0603CS-36NXGLU Coilcraft/0603CS-36NXGLU
24
1
0 R107 Ceramic chip inductor 0603CS-82NXGLU Coilcraft/0603CS-82NXGLU
25
1
0 R108 Resistor, 0402, SMD 10.0 Ω, 1/10 W, 1% Panasonic/ERJ-2RKF10R0X
26
1
0 R109 Resistor, 0402, SMD 100 kΩ, 1/10 W, 1% Panasonic/ERJ-2RKF1003X
27
1
0 R110, R111 Resistor, 0402, SMD 27.0 kΩ, 1/10 W, 1% Panasonic/ERJ-2RKF2702X
28
1
0 R116, R117 Resistor, 0402, SMD 105 kΩ, 1/16 W, 1% Panasonic/ERJ-2RKF1052X
29
1
0 R118 Resistor, 0402, SMD 4.75 kΩ, 1/10 W, 1% Panasonic/ERJ-2RKF4751X
