Item Qty
Reference
Designator Description Value Manufacturer/Part No.
72 4 J203, J402, J501, J602 CONN-PCB SMA, ST edge mount
Emerson Network Power
Connectivity Solutions/142-0711-821,
Samtec/SMA-J-P-H-ST-EM1
73 1 J205 CONN-PCB header 4P double row Samtec/TSW-102-08-G-D
74 2 J301, J701 CONN-PCB header 8-pin double row Samtec/TSW-104-08-T-D
75 1 J302 CONN-PCB header ST male, 9-pin Samtec/TSW-103-08-G-T
76 3 J403, J503, J605 CONN-PCB header 2 position, single row Samtec/TSW-102-08-G-S
77 1 J404 CONN-PCB header ST 10P Samtec/TSW-105-08-G-D
78 2 JP101, JP103 Resistor, 0805, SMD 0.0 Ω, 1/8 W, 5% Panasonic/ERJ-6GEY0R00V
79 3 JP503, L402, L501 Resistor, 0603, SMD 0 Ω, 1/10 W, 5%
Rohm Semiconductor/MCR03EZPJ000,
Panasonic/ERJ-3GEY0R00V
80 4 L403, L404, L503, L504 Resistor, 0603, SMD 0.0 Ω, 1/10 W Panasonic/ERJ-3GEY0R00V
81 1 P101 CONN power jack 2.1 mm × 5.5 mm, HI CUR CUI/PJ-002AH-SMT
82 2 P102, P103 CONN-PCB header 6 position Wieland/Z5.531.3625.0
83 3 P901, P902, P903 CONN_PCB RA connector 60 pin Tyco Electronics/6469169-1
84 1 R101 Resistor, 0402, SMD 300 Ω, 1/16 W, 1%
Rohm Semiconductor/
MCR01MZPF3000,
Panasonic/ERJ-2GEJ301X
85 1 R102 Resistor, 0402, SMD 147 kΩ, 1/10 W, 1% Panasonic/ERJ-2RKF1473X
86 1 R103 Resistor, 0402, SMD 28.0 kΩ, 1/10 W, 1% Panasonic/ERJ-2RKF2802X
87 1 R104 Resistor, 0402, SMD 10.0 Ω, 1/10 W, 1% Panasonic/ERJ-2RKF10R0X
88 2 R112, R114 Resistor, 0402, SMD 18.7 kΩ, 1/10 W, 1% Panasonic/ERJ-2RKF1872X
89 2 R113, R115 Resistor, 0402, SMD 15.0 kΩ, 1/10 W, 1% Panasonic/ERJ-2RKF1502X
90 8
R206, R208, R209,
R309, R316, R317,
R801, R802
Resistor, 0402, SMD 10.0 kΩ, 1/16 W, 1%
Yageo/RC0402FR-0710KL,
Panasonic/ERJ-2RKF1002X
91 2 R207, R733 Resistor, 0402, SMD 57.6 Ω, 1/16 W, 1% Panasonic/ERJ-2RKF57R6X
92 13
R121, R123, R310,
R311, R312, R422,
R522, R614, R704,
R705, R706, R707,
R709
Resistor, 0402, SMD 1.00 kΩ, 1/16 W, 1%
Yageo/RC0402FR-071KL,
Panasonic/ERJ-2RKF1001X
93 5
R105, R106, R313,
R314, R315
Resistor, 0402, SMD 100 kΩ, 1/16 W, 1%
Rohm Semiconductor/
MCR01MZPF1003,
Panasonic/ERJ-2RKF1003X
94 5
R403, R404, R503,
R504, R741
Resistor, 0402, SMD 33 Ω, 1/10,W, 5%
Rohm Semiconductor/
MCR01MZPJ330,
Panasonic/ERJ-2GEJ330X
95 4
R408, R409, R508,
R509
Resistor, 0402, SMD 33 Ω, 1/10,W, 5% Panasonic/ERJ-2GEJ330X
96 1 R602 Resistor, 0603, SMD 57.6 Ω, 1/10 W, 1% Panasonic/ERJ-3EKF57R6V
97 1 R710 Resistor, 0402, SMD 4.12 kΩ, 1/16 W, 1%
Vishay/CRCW04024K12FKED,
Panasonic/ERJ-2RKF4121X
98 1 R711 Resistor, 0402, SMD 5.11 kΩ, 1/16 W, 1%
Vishay/CRCW04025K11FKED,
Panasonic/ERJ-2RKF5111X
99 8
R714, R716, R725,
R730, R738, R739,
R805, R806
Resistor, 0402, SMD 200 Ω, 1/10 W, 1% Panasonic/ERJ-2RKF2000X
100 2 R726, R740 Resistor, 0402, SMD 100 Ω, 1/10 W, 5% Panasonic/ERJ-2GEJ101X
101 2 R734, R736 Resistor, 0402, SMD 130 Ω, 1/16 W, 1%
Vishay/CRCW0402130RFKED,
Panasonic/ERJ-2RKF1300X
102 2 R735, R737 Resistor , 0402, SMD 82.5 Ω, 1/16 W, 1% Panasonic/ERJ-2RKF82R5X
