Item Qty Reference Designator Description Value Manufacturer/Part No.
103
1
R401, R402, R501, R502, R601
Res prec, thick
film, chip, R0603
57.6 Ω Panasonic/ERJ-3EKF57R6V
104
1
R406, R506, R719, R720
Res prec, thick
film, chip, R0402
49.9 Ω Panasonic/ERJ-2RKF49R9X
105
1
R412
Res prec, thick
film, chip, R0402
130 Ω Panasonic/ERJ-2RKF1300X
106
1
R416 Res film, SMD, 0402 300 Ω Panasonic/ERJ-2GEJ301X
107
1
R417, R418, R419, R420, R421
Res prec, thick
film, chip, R0402
10 kΩ Panasonic/ERJ-2RKF1002X
108
1
R512, R513
Res prec, thick
film, chip, R0402
40.2 Ω Panasonic/ERJ-2RKF40R2X
109
1
R613 Res film, SMD, 0402 100 Ω Panasonic/ERJ-2GEJ101X
110
1
T403, T503 XFMR RF ADT1-1WT Mini-Circuits/ADT1-1WT
111
1
T404 XFMR RF TC3-1T+ Mini-Circuits/TC3-1T+
112
1
T505, T602
XFMR RF 1:1
(6-pin special)
MABA-007159-000000
M/A-Com/
MABA-007159-000000
113
1
TP101, TP102, TP402, TP601,
TP801, TP802
Connector-PCB,
TST PNT black
BLK
Components Corp./
TP-104-01-00
114
1
TP9, TP401, TP701, TP702,
TP703, TP704, TP705
Connector-PCB,
TST PNT white
WHT
Components Corp./
TP-104-01-09
115
1
U702
IC-ADI ultrafast, SIGe ECL
clock/data buffers
ADCLK905BCPZ-WP
Analog Devices, Inc./
ADCLK905BCPZ-WP
116
1
CR201
IC-ADI 1.2 V micropower
precision shunt voltage
reference
AD1580ARTZ
Analog Devices, Inc./
AD1580ARTZ
117
1
U202
IC-ADI single-supply,
rail-to-rail, low power
FET, input op amp
AD822BRZ
Analog Devices, Inc./
AD822BRZ
1
Do not install.
