Evaluation Board User Guide UG-003
Rev. A | Page 31 of 40
Item Qty
Reference
Designator Description Value Manufacturer/Part No.
103 9
RN801, RN802,
RN803, RN804,
RN805, RN806,
RN807, RN808, RN809
Resistor array 22 Ω, 8 term, SMD
CTS Resistor Products/
742C083220JPTR
104 5
T401, T402, T501,
T502, T602
RF 1:1 transmission line
transformer
6-pin special M/A-COM/MABA-007159-000000
105 3 U101, U104, U105
Low dropout, CMOS
linear regulator
1 A Analog Devices/ADP1708ARDZ-R7
106 2 U102, U106
Low dropout, CMOS
linear regulator
1 A Analog Devices/ADP1706ARDZ-3.3-R7
107 1 U103
Low dropout, CMOS
linear regulator
1 A Analog Devices/ADP1706ARDZ-1.8-R7
108 1 U201 DUT Analog Devices/DUT
109 1 U301
TinyLogic UHS dual buffer
(open drain outputs)
Fairchild Semiconductor/
NC7WZ07P6X
110 3 U302, U703, U803 TinyLogic UHS dual buffer
Fairchild Semiconductor/
NC7WZ16P6X
111 1 U401 Ultralow distortion IF VGA Analog Devices/AD8375ACPZ
112 1 U501
3.3 GHz ultralow distortion
RF/IF differential amplifier
Analog Devices/ADL5562_PRELIM
113 1 U701
12-output clock generator
with integrated 1.6 GHz VCO
Analog Devices/AD9517-4BCPZ
114 2 U801, U802
Low voltage 20-bit buffer/
line driver with 3.6 V tolerant
inputs and outputs and 26 Ω
series resistors in the outputs
Fairchild Semiconductor/
74VCX162827MTDX
115 1 VR101
Configurable, dual 2 A/single
4 A, synchronous step-down
dc-to-dc regulator
Analog Devices/ADP2114_PRELIM
116 1 Y601
ACMOS/LSTTL compatible
surface-mount clock OSC
Valpey Fisher/VFAC3BHL-XXMHZ
1
Do not install.
Table 4. AD9268 Family BOM
Item Qty Reference Designator Description Value Manufacturer/Part No.
1 1 Not applicable PCBZ
2 9
C101, C132, C133, C134, C135, C136,
C145, C419, C514
Capacitor, ceramic NP0 10 μF Panasonic/ECJ-2FB0J106M
3 12
C102, C103, C104, C106, C124, C126,
C127, C128, C129, C130, C144, C146
Capacitor, 0603, X5R 4.7 μF Panasonic/ECJ-1VB0J475M
4 7
C105, C117, C119, C121, C123,
C125, C143
Capacitor, ceramic,
multilayer, X7R, 0402
10,000 pF Panasonic/ECJ-0EB1E103K
5 68
C116, C118, C120, C122, C149, C150,
C151, C152, C153, C154, C204, C206,
C207, C208, C209, C211, C301, C302, C403,
C404, C405, C406, C407, C417, C418, C420,
C426, C503, C504, C505, C506, C507, C515,
C516, C523, C601, C602, C603, C606, C607,
C609, C701, C702, C710, C711, C712, C713,
C714, C715, C716, C717, C718, C719, C720,
C721, C723, C724, C730, C731, C801, C802,
C803, C804, C805, C806, C807, C808, C809
Capacitor, ceramic, 0402 0.1 μF Panasonic/ECJ-0EX1C104K
6 6 C138, C139, C141, C142, C147, C148 Capacitor, ceramic, chip 22 μF
Murata/
GRM21BR60J226ME39L
7 3 C107, C203, C205 Capacitor, ceramic 1 μF Panasonic/ECJ-0EF0J105Z
