UG-003 Evaluation Board User Guide
Rev. A | Page 32 of 40
Item Qty Reference Designator Description Value Manufacturer/Part No.
8 27
C401, C402, C502, JP403, R203, R301, R302,
R303, R304, R424, R425, R524, R525, R526,
R606, R609, R610, R611, R612, R708, R715,
R723, R727, R728, R729, R803, R804
Res film, SMD, 0402 0 Ω Panasonic/ERJ-2GE0R00X
9 1 C604 Capacitor, ceramic 1000 pF Panasonic/ECU-E1E102KBQ
10 1 C705
Capacitor, ceramic,
multilayer, X7R, 0402
1800 pF Panasonic/ECJ-0EB1E182K
11 1 C706 Capacitor, ceramic 0.033 μF
Panasonic/
0402YD333KAT2A
12 1 C707 Capacitor, ceramic, 0402 1500 pF Panasonic/ECJ-0EB1H152K
13 1 C722 Capacitor, ceramic 0.22 μF Panasonic/ECJ-0EB0J224K
14 5 CR101, CR102, CR104, CR105, CR106 Diode recovery rectifier S2A-TP
Micro Commercial
Components Corp./S2A-TP
15 1 CR103
LED green,
surface mount
LNJ308G8TRA
(green)
Panasonic/LNJ308G8TRA
16 1 CR601
Diode, Schottky,
dual series
HSMS-2812BLK
Avago Technologies/
HSMS-2812BLK
17 3 CR701, CR801, CR802 LED red, surface mount SML-LXT0805IW-TR Lumex/SML-LXT0805IW-TR
18 12
E101, E102, E103, E105, E107, E109,
E110, E111, E112, E113, E114, E115
Inductor ferrite bead 100 MHz
Panasonic/
EXC-ML20A390U
19 1 F101
Fuse, polyswitch,
PTC device
1.6 A
Tyco Electronics/
MINISMDC160F-2
20 1 FL101
Filter noise suppression,
LC-combined type
BNX016-01 Murata/BNX016-01
21 1 J201
Connector-PCB, Berg,
header, double STR,
male, 6 pos
TSW-103-08-G-D Samtec/TSW-103-08-G-D
22 4 J203, J402, J501, J602
Connector-PCB,
SMA, ST edge mount
SMA-J-P-X-ST-EM1 Samtec/SMA-J-P-X-ST-EM1
23 1 J205
Connector-PCB,
header, 4 pos, ST
TSW-102-08-G-D Samtec/TSW-102-08-G-D
24 2 J301, J701
Connector-PCB, header,
8 pos, double row
TSW-104-08-T-D Samtec/TSW-104-08-T-D
25 1 J302
Connector-PCB, header,
ST male, 9 pos
TSW-103-08-G-T Samtec/TSW-103-08-G-T
26 3 J403, J503, J605
Connector-PCB,
header, 2 pos
TSW-102-08-G-S Samtec/TSW-102-08-G-S
27 1 J404
Connector-PCB,
header, ST, 10 pos
TSW-105-08-G-D Samtec/TSW-105-08-G-D
28 2 JP101, JP103
Res jumper,
SMD, 0805 (SHRT)
0 Ω Panasonic/ERJ-6GEY0R00V
29 3 JP503, L402, L501 Res film, SMD, 0603 0 Ω Panasonic/ERJ-3GEY0R00V
30 4 L403, L404, L503, L504 Inductor, ferrite bead 10 Ω @ 100 MHz Murata/BLM18BA100SN1
31 1 P101
Connector-PCB, power
jack, surface mount
PJ-002AH-SMT CUI, Inc./PJ-002AH-SMT
32 2 P102, P103
Connector-PCB,
header, 6 pos
Z5.531.3625.0 Wieland/Z5.531.3625.0
33 3 P901, P902, P903
Connector-PCB,
60-pin, RA connector
6469169-1 Tyco Electronics/6469169-1
34 1 R101 Res film, SMD, 0402 300 Ω Panasonic/ERJ-2GEJ301X
35 1 R102
Res prec, thick
film, chip, R0402
147 kΩ Panasonic/ERJ-2RKF1473X
36 1 R103
Res prec, thick
film, chip, R0402
28 kΩ Panasonic/ERJ-2RKF2802X
37 1 R104
Res prec, thick
film, chip, R0402
10 Ω Panasonic/ERJ-2RKF10R0X
38 2 R112, R114
Res prec, thick
film, chip, R0402
18.7 kΩ Panasonic/ERJ-2RKF1872X
