UG-003 Evaluation Board User Guide
Rev. A | Page 38 of 40
Item Qty Reference Designator Description Value Manufacturer/Part No.
68 1 Y601-20 for -20 model U201
IC clock OSC, ACMOS/
LSTTL compatible
20 MHz
Valpey Fisher/
VFAC3BHL-20MHZ
69
1
C108, C109
Capacitor, ceramic,
multilayer, X7R 0402
10,000 pF Panasonic/ECJ-0EB1E103K
70
1
C110 Capacitor, ceramic 2200 pF
Phy Comp (Yageo)/
CC0402KRX7R9BB222
71
1
C111, C113, C519
Capacitor, chip, mono,
ceramic, C0G, 0402
100 pF
Murata/
GRM1555C1H101JD01D
72
1
C112 Capacitor, ceramic, 0402 1500 pF Panasonic/ECJ-0EB1H152K
73
1
C137, C140
Capacitor, ceramic,
SMD, 0603
N/A N/A
74
1
C408, C409, C411, C508, C509, C511 Capacitor, ceramic, NP0 5 pF Panasonic/ECJ-E1H050CCQ
75
1
C201, C202, C412, C413, C414, C415,
C416, C421, C427, C512, C513, C521,
C522, C601, C703, C704, C708, C709
Capacitor, ceramic, 0402 0.1 μF Panasonic/ECJ-0EX1C104K
76
1
C422, C423
Capacitor, ceramic,
multilayer, X7R, 0402
1200 pF Panasonic/ECJ-0EB1E122K
77
1
C424 Capacitor, ceramic 2.7 pF Samsung/CL05C2R7CBNC
78
1
C425
Capacitor, mono,
ceramic, C0G, 0402
20 pF
Murata/
GRM1555C1H200JZ01D
79
1
C517, C518 Capacitor, ceramic 1000 pF Panasonic/ECU-E1E102KBQ
80
1
C520 Capacitor, ceramic 39 pF
Phy Comp (Yageo)/
0402CG390J9B200
81
1
E104, E106, E108, E116, E117, E118, E119 Inductor ferrite bead 100 MHz Panasonic/EXC-ML20A390U
82
1
J401, J502, J601, J702, J703, J704
Connector-PCB, SMA,
ST edge mount
SMA-J-P-X-ST-EM1 Samtec/SMA-J-P-X-ST-EM1
83
1
JP102, JP104
Res jumper, SMD,
0805 (SHRT)
0 Ω Panasonic/ERJ-6EY0R00V
84
1
L101, L102 Inductor, SM 2.2 μH TOKO/FDV0630-2R2M
85
1
L401, L502 Res film, SMD, 0603 0 Ω Panasonic/ERJ-3GEY0R00V
86
1
L405, L505 Inductor, SM 100 nH Coilcraft/0603CS-R10XGLU
87
1
L406, L407 Inductor, SM 1 μH Coilcraft/0603LS-102XGLB
88 L408, L409, L410, L411 Inductor, SM 270 nH Coilcraft/0603CS-R27XGLW
89
1
L508, L509 Chip inductor 15 nH Coilcraft/0603CS-15NXGLU
90
1
L510, L520 Chip inductor 36 nH Coilcraft/0603CS-36NXGLU
91
1
L521, L522 Inductor, SM 82 nH Coilcraft/0603CS-82NXGLU
92
1
R107 Res chip, SMD, 0402 27 kΩ Panasonic/ERJ-2RKF2702X
93
1
R108
Res prec, thick
film chip, R0402
10.5 kΩ Panasonic/ERJ-2RKF1052X
94
1
R109 Res chip, SMD, 0402 4.75 kΩ Panasonic/ERJ-2RKF4751X
95
1
R110, R111 Res chip, SMD, 0402 15 kΩ Panasonic/ERJ-2RKF1502X
96
1
R116, R117 Res chip, SMD, 0603 N/A N/A
97
1
R118 Res chip, SMD, 0402 13 kΩ Yageo/9C04021A1302FLHF3
98
1
C501, JP401, JP402, JP501, JP502, R120,
R122, R124, R125, R126, R127, R305,
R306, R307, R308, R405, R407, R410,
R411, R413, R414, R415, R423, R505,
R507, R510, R511, R514, R515, R516,
R517, R519, R520, R521, R603, R604,
R605, R607, R608, R721, R722, R731, R732
Res film, SMD, 0402 0 Ω Panasonic/ERJ-2GE0R00X
99
1
R518
Res prec, thick
film, chip, R0402
1.00 kΩ Panasonic/ERJ-2RKF1001X
100
1
R201
Res prec, thick
film, chip, R0402
2 kΩ Panasonic/ERJ-2RKF2001X
101
1
R202
Res VAR 3-/8-inch,
SQ top adj
10 kΩ Bourns, Inc./3299W-1-103
102
1
R204, R205 Res chip, SMD, 0402 N/A N/A
