AD9640
Rev. B | Page 18 of 52
Pin No. Mnemonic Type Function
Digital Inputs
52 SYNC Input Digital Synchronization Pin. Slave mode only.
Digital Outputs
63 D0+ (LSB) Output Channel A/Channel B LVDS Output Data 0—True.
62 D0− (LSB) Output Channel A/Channel B LVDS Output Data 0—Complement.
3 D1+ Output Channel A/Channel B LVDS Output Data 1—True.
2 D1− Output Channel A/Channel B LVDS Output Data 1—Complement.
5 D2+ Output Channel A/Channel B LVDS Output Data 2—True.
4 D2− Output Channel A/Channel B LVDS Output Data 2—Complement.
7 D3+ Output Channel A/Channel B LVDS Output Data 3—True.
6 D3− Output Channel A/Channel B LVDS Output Data 3—Complement.
9 D4+ Output Channel A/Channel B LVDS Output Data 4—True.
8 D4− Output Channel A/Channel B LVDS Output Data 4—Complement.
13 D5+ Output Channel A/Channel B LVDS Output Data 5—True.
12 D5− Output Channel A/Channel B LVDS Output Data 5—Complement.
15 D6+ Output Channel A/Channel B LVDS Output Data 6 —True.
14 D6− Output Channel A/Channel B LVDS Output Data 6—Complement.
17 D7+ Output Channel A/Channel B LVDS Output Data 7—True.
16 D7− Output Channel A/Channel B LVDS Output Data 7—Complement.
19 D8+ Output Channel A/Channel B LVDS Output Data 8—True.
18 D8− Output Channel A/Channel B LVDS Output Data 8—Complement.
23 D9+ Output Channel A/Channel B LVDS Output Data 9—True.
22 D9− Output Channel A/Channel B LVDS Output Data 9—Complement.
26 D10+ Output Channel A/Channel B LVDS Output Data 10—True.
25 D10− Output Channel A/Channel B LVDS Output Data 10—Complement.
28 D11+ Output Channel A/Channel B LVDS Output Data 11—True.
27 D11− Output Channel A/Channel B LVDS Output Data 11—Complement.
30 D12+ Output Channel A/Channel B LVDS Output Data 12—True.
29 D12− Output Channel A/Channel B LVDS Output Data 12—Complement.
32 D13+ (MSB) Output Channel A/Channel B LVDS Output Data 13—True.
31 D13− (MSB) Output Channel A/Channel B LVDS Output Data 13—Complement.
11 DCO+ Output Channel A/Channel B LVDS Data Clock Output—True.
10 DCO− Output Channel A/Channel B LVDS Data Clock Output—Complement.
SPI Control
48 SCLK/DFS Input SPI Serial Clock/Data Format Select Pin in External Pin Mode.
47 SDIO/DCS Input/Output SPI Serial Data I/O/Duty Cycle Stabilizer in External Pin Mode.
51 CSB Input SPI Chip Select (Active Low).
Signal Monitor Ports
33 SMI SDO/OEB Input/Output Signal Monitor Serial Data Output/Output Enable Input (Active Low) in External Pin Mode.
35 SMI SDFS Output Signal Monitor Serial Data Frame Sync.
34 SMI SCLK/PDWN Input/Output Signal Monitor Serial Clock Output/Power-Down Input in External Pin Mode.
