AD9640
Rev. B | Page 20 of 52
TYPICAL PERFORMANCE CHARACTERISTICS
AVDD = 1.8 V; DVDD = 1.8 V; DRVDD = 3.3 V; sample rate = 150 MSPS, DCS enabled, 1 V internal reference;
2 V p-p differential input; VIN = −1.0 dBFS; and 64k sample; T
A
= 25°C, unless otherwise noted.
0
–120
0
06547-050
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 7060
150MSPS
2.3MHz @ –1dBFS
SNR = 71.9dBc (72.9dBFS)
ENOB = 11.8 BITS
SFDR = 86dBc
SECOND HARMONIC
THIRD HARMONIC
Figure 16. AD9640-150 Single-Tone FFT with f
IN
= 2.3 MHz
0
–120
0
06547-051
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 7060
150MSPS
30.3MHz @ –1dBFS
SNR = 71.7dBc (72.7dBFS)
ENOB = 11.8 BITS
SFDR = 89.9dBc
SECOND HARMONIC
THIRD HARMONIC
Figure 17. AD9640-150 Single-Tone FFT with f
IN
= 30.3 MHz
0
–120
0
06547-052
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 7060
150MSPS
70MHz @ –1dBFS
SNR = 71.5dBc (72.5dBFS)
ENOB = 11.7 BITS
SFDR = 84dBc
SECOND HARMONIC
THIRD HARMONIC
Figure 18. AD9640-150 Single-Tone FFT with f
IN
= 70 MHz
0
–120
0
06547-053
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 7060
150MSPS
140.3MHz @ –1dBFS
SNR = 70.9dBc (71.9dBFS)
ENOB = 11.6 BITS
SFDR = 85.1dBc
SECOND HARMONIC
THIRD HARMONIC
Figure 19. AD9640-150 Single-Tone FFT with f
IN
= 140.3 MHz
0
–120
0
06547-054
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 7060
150MSPS
200.3MHz @ –1dBFS
SNR = 70dBc (71dBFS)
ENOB = 11.5 BITS
SFDR = 80dBc
SECOND HARMONIC
THIRD HARMONIC
Figure 20. AD9640-150 Single-Tone FFT with f
IN
= 200.3 MHz
0
–120
0
06547-085
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 7060
150MSPS
337MHz @ –1dBFS
SNR = 68dBc (69dBFS)
ENOB = 11 BITS
SFDR = 72.4dB
SECOND HARMONIC
THIRD HARMONIC
Figure 21. AD9640-150 Single-Tone FFT with f
IN
= 337 MHz
