AD9640
Rev. B | Page 21 of 52
0
–120
0
06547-086
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 7060
150MSPS
440MHz @ –1dBFS
SNR = 65dBc (66dBFS)
ENOB = 10.4 BITS
SFDR = 70.0dB
SECOND HARMONIC
THIRD HARMONIC
Figure 22. AD9640-150 Single-Tone FFT with f
IN
= 440 MHz
0
–120
0
06547-057
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 60
125 MSPS
2.3MHz @ –1dBFS
SNR = 72.3dBc (73.3dBFS)
ENOB = 11.8 BITS
SFDR = 88.4dBc
SECOND HARMONIC
THIRD HARMONIC
Figure 23. AD9640-125 Single-Tone FFT with f
IN
= 2.3 MHz
0
–120
0
06547-058
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 60
125 MSPS
30.3MHz @ –1dBFS
SNR = 72.1dBc (73.1dBFS)
ENOB = 11.8 BITS
SFDR = 89.1dBc
THIRD HARMONIC
SECOND HARMONIC
Figure 24. AD9640-125 Single-Tone FFT with f
IN
= 30.3 MHz
0
–120
0
06547-093
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 60
125MSPS
70MHz @ –1dBFS
SNR = 71.8dBc (72.8dBFS)
ENOB = 11.7 BITS
SFDR = 85dBc
SECOND HARMONIC
THIRD HARMONIC
Figure 25. AD9640-125 Single-Tone FFT with f
IN
= 70 MHz
0
–120
0
06547-059
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 60
125 MSPS
140MHz @ –1dBFS
SNR = 71.4dBc (72.4dBFS)
ENOB = 11.7 BITS
SFDR = 87.1dBc
SECOND HARMONIC
THIRD HARMONIC
Figure 26. AD9640-125 Single-Tone FFT with f
IN
= 140 MHz
0
–120
0
06547-060
FREQUENCY (MHz)
AMPLITUDE (dBFS)
–20
–40
–60
–80
–100
10 20 30 40 50 60
125 MSPS
200MHz @ –1dBFS
SNR = 70.8dBc (71.8dBFS)
ENOB = 11.6 BITS
SFDR = 80.5dBc
SECOND HARMONIC
THIRD HARMONIC
Figure 27. AD9640-125 Single-Tone FFT with f
IN
= 200 MHz
