4-3. WORKING WITH THE SMART MATRIX

Operating modes

The Smart MatriX offers 1 mode to work from: the Native Matrix mode, which turns your Smart MatriX into

a true 12 x 2 scaled matrix with numerous Live effects and PIPs and logos.

Reseting default values

It is strongly recommended that you reset all of the default values of your Smart MatriX unit before setting up

your shows and events. To do so, press the EXIT/MENU button and select Control in the menu by rotating the

corresponding knob. Then press the ENTER button to enter the Control sub-menu. Select Default Values by

rotating the scroll knob, and press the ENTER button to enter your choice to restart your Smart MatriX with its

factory settings. This operation should take approximately 30 seconds.

Smart MatriX color codes

Analog Way engineers have developed a handy, user friendly way of identifying machine status on the front

panel, via the use of color codes on the buttons of the machine. All new Analog Way machines use the same

codes, for quick recognition of the status of any device of the range, at any given time.

Solid green: Function available for modication

Dim red: Stand-by button
