SPIReadDigital

SPIReadDigital — Reads the current values of digital input and output registers of the AnaGate device.

Syntax

#include <AnaGateDllSPI.h>

int SPIReadDigital(int hHandle, unsigned long * pnInputBits, unsigned

long * pnOutputBits);

Parameter

hHandle Valid access handle.

pnInputBits Pointer to the current value of the digital input register. Currently only bits 0 to 3 are

used, other bits are reserved for future use and are set to 0.

pnOutputBits Pointer to the current value of the digital output register. Currently only bits 0 to 3 are

used, other bits are reserved for future use and are set to 0.

Return value

Returns Null if successful, or an error value otherwise (Appendix A, Return Codes).

Description

All models of the AnaGate series (except the model AnaGate CAN uno in DIN rail case) have connectors

for 4 digtial inputs and 4 digital outputs at the rear panel.

The current values of the digital inputs and outputs can be retrieved with the SPIReadDigital function.

See the following example for setting an reading the digital IO.

#include <AnaGateDllSPI.h>

int main()

{

int hHandle = 0;

int nRC = 0;

unsigned long nInputs;

unsigned long nOutputs = 0x03;

int nRC = SPIOpenDevice(&hHandle, "192.168.0.254", 5000);

if ( nRC == 0 )

{

// set the digital output register (PIN 0 and PIN 1 to HIGH value)

nRC = SPIWriteDigital( hHandle, nOutputs );

// read all input and output registers

nRC = SPIReadDigital( hHandle, &nInputs, &nOutputs );

SPICloseDevice(hHandle);

}

return 0;
