Installation & Assembly

WARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER .
ASSEMBLING THE FIXTURE (Fig.1)
1. Shut off the power at the circuit breaker box. Remove old fixtur
e
and
all hardware from Junction Box.
2. Carefully unpack your new fixture and lay out all the parts on a
clear area. Take care not to lose any small parts necessary for
in
stallation.
3. Attach the tube (J) to the coupling of the fixture body(K) , att
ach
t
he tube (I) and (H) onto the pipe nipple of the tube (J), by turning
it clockwise until tight. Attach the open link(O) hook the small loop
of canopy(F) and tube(H), then close the open link(O)
.
4. En
d of pipe nipple screw(C) into single bar (D), place lock washer
(B) over end of nipple protruding through single bar and lock it
securely with the hex nut (A). Take this single bar assembly to
junction box with junction box screws (E), tighten screws securely
with screwdriver. The side of the single bar marked "GND" must
face to out.
5. While holding the canopy towards the ceiling , connect the
electrical wires as Shown i
n Fig.2, making sure that all wire nuts
are secured. You may have to wrap the connections with
electrical
tap
e. If your outlet has a ground wire (green or bare copper),
connect the fixture ground wire to it. Otherwise connect fixture’s
ground wire directly to the Single bar with the green
screw
p
rovided. After wires are connected, tuck them carefully inside the
Junction Box.
6. Install the light bulbs in accordance with the fixture’s
specifications. NOTE: DO NOT EXCEED THE SPECIFIED
WATTAGE.
7. Raise the fixture body on to the Junction box, aligning screws on
single bar with mounting hole in canopy and lock it securely with
the finial (G). Attach the big ring(M) onto the glass(N), raise th
e
g
lass(N) into the lamp holder cover, lock it securely with th
e
screws
(L) on si
de.
Your installation is now complete Return power to the junction
box and test the fixture.
Fig.1
2
Fig.2
:KLWHRU
+286(
%ODFN
:,5(6
+RW
6PRRWK
),;785(
:,5(6
%ODFNRU
5LEEHG
:,5(6
),;785(
%DUH&RSSHU*URXQG
),;785(
:,5(6
&RSSHU
*URXQG
+286(
1HXWUDO
:,5(6
:KLWH
%DUH
*UHHQRU
:,5(6
+286(
(Not included)
ASSEMBLING & INSTALLATION INSTRUCTIONS PRODUCT
