Installation Instruction

ManualsBrandsAndrew Wireless System ManualsElectronicsPublic Safety Repeater

The Remote Unit, Extension Unit or Master Unit must be

mounted by proffessionel / special trained installer.

1.1. MECHANICAL INSTALLATION

1.1.1. Health and Safety for Mechanical Installation

1. Caution: Risk of injury by the considerable weight of the unit falling. Ensure there is

adequate manpower to handle the weight of the system.

2. Caution: Risk of serious personal injury by equipment falling due to improper installation.

The installer must verify that the supporting surface will safely support the combined load

of the electronic equipment and all attached hardware and components. The screws and

dowels (wall anchors) used should also be appropriate for the structure of the supporting

wall.

3. Caution: Explosive atmospheres. To avoid explosion or fire, do not operate this equipment

in the presence of flammable gases or fumes.

4. Caution: Lightning danger. Do not install or make adjustments to this equipment during an

electrical storm.

1.1.2. Property Damage Warnings for Mechanical Installation

1. Attention: Do not install the unit in a way or at a place where the specifications outlined in

the Environmental and Safety Specifications leaflet of the supplier are not met. Otherwise,

the lifespan and performance of the repeater may be reduced.

2. Attention: Due to power dissipation, the unit may reach a very high temperature. Ensure

sufficient airflow for ventilation.

3. Attention: The repeater must be installed in a vertical position.

4. Notice: Exceeding the specified load limits may cause the loss of warranty.

5. Notice: Do not place cables or tools that may damage the repeater in close proximity to it.

6. Notice: Do not wear jewelry or metal accessories when installing this repeater.

7. Notice: When connecting and mounting the cables (RF, optical, mains, ...) ensure that no

water can penetrate into the unit through these cables.

8. Notice: Check all cables for shorts and opens. Verify that there are no cables with loose or

poor connections. RF leakage could cause oscillation to occur under some conditions.

9. Notice: If any different or additional mounting material is used, ensure that the mounting

remains as safe as the mounting designed by the manufacturer. The specifications for

stationary use of the Unit must not be exceeded. Ensure that the static and dynamic

strengths are adequate for the environmental conditions of the site. The mounting itself

must not vibrate, swing or move in any way that might cause damage to the Unit.

10. Notice: A spacing of 40 mm (1.58 inch) around the unit is required.

Summary of content (9 pages)

PAGE 1
Installation Instruction The Remote Unit, Extension Unit or Master Unit must be mounted by proffessionel / special trained installer. 1.1. MECHANICAL INSTALLATION 1.1.1. Health and Safety for Mechanical Installation 1. Caution: Risk of injury by the considerable weight of the unit falling. Ensure there is adequate manpower to handle the weight of the system. 2. Caution: Risk of serious personal injury by equipment falling due to improper installation.
PAGE 2
Specified torques must be observed for certain mounting procedures according to the following table: Type Pins Hex nuts Screws Thread M6 M6 M6 Specified torques 3.3 Nm 3.3 Nm 3.
PAGE 3
ELECTRICAL INSTALLATION 1.2. 1.2.1. Health and Safety for Electrical Installation Read and observe chapter 1.3 Health and Safety. 1. Danger: Electrical hazard. Danger of death or fatal injury from electrical current. Obey all general and regional installation and safety regulations relating to work on high voltage installations, as well as regulations covering correct use of tools and personal protective equipment. 2. Danger: Electrical hazard.
PAGE 4
1.3. HEALTH AND SAFETY 1. Danger: Electrical hazard. Danger of death or fatal injury from electrical current. Obey all general and regional installation and safety regulations relating to work on high voltage installations, as well as regulations covering correct use of tools and personal protective equipment. 2. Danger: Electrical hazard. Danger of death or fatal injury from electrical current inside the unit in operation. Before opening the unit, disconnect mains power. 3.
PAGE 5
1.3.2. Compliance 1. Notice: For installations, which have to comply with FCC RF exposure requirements, the antenna selection and installation must be completed in a way to ensure compliance with those FCC requirements.
PAGE 6
Antenna Stmt for ISED: This device has been designated to operate with the antennas having a maximum gain of 9 dBi. Antennas having a gain greater than 9 dBi are prohibited for use with this device without consent by ISED regulators. The required antenna impedance is 50 ohms.
PAGE 7
5. Notice: The unit complies with Overvoltage Category II. It also complies with the requirement according to EN 61000-4-5 (fine protection); however, installation additional medium (via local supply connection) and/or coarse protection (external protection) is recommended depending on the individual application in order to damage caused by overcurrent. surge of an surge avoid For Canada and US, components used to reduce the Overvoltage Category shall comply with the requirements of IEC 61643-series.
PAGE 8
Equipment Symbols Used / Compliance Please observe the meanings of the following symbols used in our equipment and the compliance warnings: Symbol Compliance --- FCC --- ISED Meaning / Warning For industrial (Part 90) signal booster, Class B: This is a 90.219 Class B device. WARNING: This is NOT a CONSUMER device. It is designed for installation by FCC LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express consent of an FCC Licensee to operate this device.
PAGE 9
WEEE Recycling Country specific information about collection and recycling arrangements per the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations is available on CommScope’s website. http://www.commscope.
