TC Series Cutting Plotter User’s Manual Thank you very much for purchasing LIYUTM TC Series Cutting Plotter. To ensure correct and safe usage with a full understanding of this product's performance, please be sure to read through this manual completely and store it in a safe location. The contents of this operation manual and the specifications of this product are subject to change without notice. The operation manual and the product have been prepared and tested as much as possible.
User’s Manual of TC Series Cutting Plotter Table of Contents Chap 1 Attention.................................................................................…....……….....3 Chap 2 Part Names and Functions.....................................................……….……..4 2-1 Accessories.......................................................................................…..…….......4 2-2 Introduction of main machine................................................................……...…...
User’s Manual of TC Series Cutting Plotter Chap 1 Attention Ensure the supply voltage to the TMC Series Cutting Plotter is AC220V and varying within the range of ±10%, otherwise a voltage stabilizer must be used. Please don’t place any small iron-magnetic subject near the carriage. Prevent from dropping foreign matters into cracks such as pins, little screws, etc. Please pull down the power plug if not using during a long time. Don’t press the pinch roller on the grit roller, if it is not used.
User’s Manual of TC Series Cutting Plotter Chap 2 Part Names and Functions 2-1 Accessories NO. Item Quantity 1 Main machine 1 2 Cutter holder 1 3 Plotter holder 1 4 Refill 1 5 Cutter 3 6 USB cable 1 7 Power cord 1 8 Machine cover 1 9 Operation manual 1 10 Guarantee certificate 1 Note ： There is a free special machine stand for the size 800 and larger machines. 2-2 Introduction of main machine 1.Left cover 2.Cover of guide 3.Panel 4.Pinch roller 5.Carriage 6.
User’s Manual of TC Series Cutting Plotter 2-3 Parts of stand and assembly 1 Parts of stand NO.
User’s Manual of TC Series Cutting Plotter 2-4 Cutter/Plotter 1 Structure of cutter holder and items of components Rotate the cutter holder to adjust the out-stretching length of the cutter as to ensure that it doesn’t cut off the bottom layer of stickness (consists of upper and bottom layer). 1. 2. 3. 4. 5.
User’s Manual of TC Series Cutting Plotter 2-5 Parameters table ITEMS / MODEL TC631 /801 TC1061/1261 Maximum cutting size 630mm/800mm 1060mm/1260 Maximum media size 710mm/880mm 1130 mm/1350 800 mm/s Cutting speed (8—800)g Cutting force 0.025mm/step Mechanical resolution Buffer capacity 8MB Repeatability 0.
User’s Manual of TC Series Cutting Plotter Chap 3 Operation Directions 3-1 Installation of the USB driver During the installing of the USB driver, any operate to the controlling-panel is invalidation. 1 Turn on the power and connect the USB cable with the computer.
User’s Manual of TC Series Cutting Plotter 3 Select , then click 4 Select , then click ９ ; ;
User’s Manual of TC Series Cutting Plotter 5 Select as following drawing, then click 6 Click ; ; １０
User’s Manual of TC Series Cutting Plotter 7 Click ,choose the LiYuDrv and install(in the CD-ROM/USB Drv); １１
User’s Manual of TC Series Cutting Plotter １２
User’s Manual of TC Series Cutting Plotter 8 Click for finish the installation of the USB driver; １３
User’s Manual of TC Series Cutting Plotter 9 After installation，the device will appeared in the Device Manager as follows，please change the port number according to the require of the computer.
User’s Manual of TC Series Cutting Plotter 3-2 Controlling-panel operations Controlling-panel Static screen: In the connecting state, when waiting for the data inputting, LCD displays: SPD：6 PRS：8 LOCAL TEST COPY Therein, SPD:6 means the current speed is the sixth level, PRS:8 means the current press is the eighth level. Dynamic screen: In the connecting state, when cutting by the order of computer, LCD displays: SPD：6 PRS：8 NOW IS CUTTING...
User’s Manual of TC Series Cutting Plotter Original point: The place of cutter/plotter just at the time of confirming “LOCAL” state. Select key: In the static screen state, press this key can select “LOCAL”, “TEST” and “COPY” function in sequence. Enter key: After select an option, press this key can confirm your selection and process the next step. Reset key: Reset the circuit of the machine. After press this key, the carriage can move to right or left according the type of the last working file.
User’s Manual of TC Series Cutting Plotter Test function: Under the static screen, press SELECT key to select “TEST” function, then press ENTER key, the machine will plot self-check graph. Light:ON OFF: When the cursor in the “ON”, press ENTER key can choose the Light ON or OFF, the LCD does not quit this interface and displays: SPD：6 PRS：8 ORIGIN CURRENT ON 3-3 Operation skills 1 Loading the paper 1. Lift the pinch-roller handle and let it away from the roller. 2.
User’s Manual of TC Series Cutting Plotter 3 Lift up / adhere When cutting over… 1. Cut off the paper with scissors or a knife. 2. Get rid of the useless part with tweezers (you can easily do this if you add a side frame around the pattern when cutting). 3. Adhere a special “over-pasted film” on the cut pattern and stroke it with scraper. 4. Lift up the “over-pasted film” and paste it on the any place you want, tear the film off. a then 4 After work is over… 1. Lift the pinch-roller handle. 2.
User’s Manual of TC Series Cutting Plotter Chap 4 FAQ Question 1: What shall I do if I can not enter into the cutting system? Answer: 1. The files of the cutting system are damaged. Reinstall the cutting system with the CD-ROM enclosed. 2. Check the cutting system is running or not with press the “Alt”+ “Tab” keys on your keyboard. Question 2: What shall I do if the “Cutting output” option is invalided after I enter into the cutting system? Answer: 1. Check the dongle/key is installed correct or not.
User’s Manual of TC Series Cutting Plotter knifepoint will pick the film and cause the waster. 2. Suggest using the compensation function for best effect when cutting the small pattern. The angle compensation should be set between 0.3mm to 0.5mm according to the fact. 3. The knifepoint should be shorter than normal length for cutting a more smooth small pattern. Question 5: What shall I pay attention to the large cutting? Answer: 1.
User’s Manual of TC Series Cutting Plotter Question 8: Why the paper cannot return to the original point? Answer: 1. Wrong operation on the pinch-rollers. 2. The pinch-rollers is frayed badly. 3. The paper is not loaded rightly. 4. No test running of the paper before cutting the long pattern. Question 9: Phenomena Not Wrong. 1. The controlling-panel does not respond when the computer is restarting and the USB cable has connected with the computer.
