Antec TruePower 2.0 User's Manual ATX12V version 2.0 power supply Models: TPII-380, TPII-430, TPII-480, TPII-550, TPII-480Blue, TrueControl II-550 TruePower 2.0 series power supplies comply with the newest ATX12V version 2.0 specifications. This includes dual 12V output circuitry that delivers safer and more reliable output to your system's components, as well as higher energy efficiency, which reduces power consumption by up to 25%, saving you money on your electricity bill.
equipped with a soft on/off feature which turns your computer on and off through the soft switch on your computer case. You may need to turn the switch to the OFF position occasionally should your computer crash and you cannot shut it down using the soft switch. Installation: 1. Disconnect the power cord from your old power supply. 2. Open your computer case. Follow the directions provided in your case manual. 3.
To measure the +12V1, +12V2, +5V and +3.3V outputs: 1. Set the measuring dial of your meter to VDC. Choose a maximum measuring range of +20VDC or higher. 2. To measure the +12V1 output: Use a 4-pin Molex connector from the power supply and insert the positive pole (red) to the connector pin with the yellow wire. Insert the negative (black) to one of the connector pins with a black ground wire. 3.
Using TrueControl II-550: 1. The default voltages are set at +12V, +5V, and +3.3V. Turn the knob clockwise to increase output voltage and counterclockwise to decrease output voltage. The range within which you can adjust the voltage is ±5% of the specified output voltage (see Table 1). Note: Changing the output settings does not affect the voltage feedback circuitry, so if for example you set your +5V output to +5.2V, the power supply voltage feedback will operate to keep the +5V output as close to +5.
