INSTALLATION
PERFECTION IS OUR TRADITION™
pg. 8
Put the trim plate (#14) through the faucet valve then fasten it with screws (#17) and tighten
using screw driver.
Place the mixing valve handle (#13), secure with set screw (#12).
Finally, insert the index (#20).
Step 5A
Step 5B
Step 5C
O-rin g
2
1
15
14
18
3
15
14
18
