Installation Guide

Figure 4

INSTALLATION

PERFECTION IS OUR TRADITION™

pg. 7

Apply Teflon tape to the shower arm (#2) then place shower arm flange (#1) on shower pipe

and screw shower arm to the pipe.

After shower arm is in place screw the shower head (#3) onto the arm.

Make sure the O-ring is placed in between the shower arm (#2) and the shower

head (#3).

Step 4A

Step 4B

Important:

O-rin g

O-r ing
