203Vw+ User Manual 1. Preface About This Guide This guide describes the monitor's features, setup, and operation. lnformation in this document is subject to change without notice. The sections are as follows: • • • • • • • Safety Instructions: lists safety information. Setup: describes the initial setup process. Using the Monitor: gives an overview of how to use the monitor. Drivers: provides driver installation instructions for Windows. Technical Support : provides tips and solutions for common problems.
Some warnings may appear in alternate formats and may be unaccompanied by an icon. In such cases, the specific presentation of the warning is mandated by regulatory authority. Product Registration Please link www.aoc.com, select your country or region, log in Product Registration to register. 2.
This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
3. Setup Setup the stand and base Please setup or remove the base following below steps. Adjusting Viewing Angle • • • • For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your own preference. Hold the stand so you do not topple the monitor when you change the monitor's angle. You are able to adjust the monitor's angle from -5°to 20°.
NOTE: Do not touch the LCD screen when you change the angle. It may cause damage or break the LCD screen.
1.Power 2. DVI 3. Analog Turn off your computer before performing the procedure below. 1. 2. 3. Connect the power cable to the AC port on the back of the monitor. Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the computer's D-Sub port. Turn on your monitor and computer. If your monitor displays an image, installation is complete. If it does not display an image, see Troubleshooting.
This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this procedure.
1. 2. 3. 4. 5. Remove the base. Follow the manufacturer's instructions to assemble the wall mounting arm. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in the back of the monitor. Insert the 4 screws into the holes and tighten. Reconnect the cables. Refer to the user's manual that came with the optional wall mounting arm for instructions on attaching it to the wall. 4.
1. Auto Config 2. + 3. Eco Mode/ 4. Menu / Enter 5. Power Button & Indicator OSD Settings • • • • • Press the MENU-button to activate the OSD window. Press+ or - to navigate through the functions. Once the desired function is highlighted, press the MENU-buttonto activate it.If the function selected has a submenu, press or again to navigate through the sub-menu functions.Once the desired function is highlighted, press MENU-button to activate it. Press+ or - to change the settings of the selected function.
DCB Adjustment What is DCB? Dynamic Color Boost (DCB) is an advanced color adjustment technology. Through analyzing RGB signals, DCB creates more vivid and natural images to suit various color environment needs. DCB has two types of color enhancers: “Color Boost” and “Picture Boost” .
automatically due to the color correlation between RGB and YBM. Five color-enhancement settings: To accommodate various display needs, Color Boost also offers 5 different color enhancement modes: Full Enhance, Natural Skin, Green Field, Sky Blue, and Auto-Detect. Please go to the fourth icon labeled “Color Boost” in the OSD menu and select one of the five settings you desire to be turned on.
Full Enhance: When "Full Enhance" is turned on, the color saturation of the entire screen is fully enriched, thus all colors become more vibrant. Nature Skin: When "Natural Skin" is turned on, the red and yellow colors are enriched automatically, thus presents human skin with more natural and truer colors. "Natural Skin" setting is ideal for viewing human portrait and detailed skin texture.
Green Field: When "Green Field" is turned on, the green color is enriched so that football field and mountain landscape would look more natural and fresh. “Green Field” setting is ideal for watching mountain scenery and outdoor sports. Sky Blue: When"Sky Blue" is turned on, the color blue is being fine-tuned so that the sky or ocean landscape will look more vivid and in-depth. "Sky Blue" setting is ideal for viewing sky and ocean images.
Auto Detect: Demo: When “Auto Detect” is turned on, every pigment will be detected and self-adjusted to render a lively picture. Screen divided into two for demonstration purposes. 2) How to use Picture Boost? Users can change the color settings of a self-selected zone on the screen. The size and position of the selected zone can also be adjusted. "Picture Boost" is located in the fifth icon labeled "Picture Boost" in the OSD menu. Turn on "Bright Frame" to select a zone on the screen to be enhanced.
one of the DCB features, the rest of color settings including DCR will be disabled or return to default. Disclaimer: DCB aftereffects are subject to the resolution and quality of the display content, hence may look different than the above illustrations. DCR Adjustment What is DCR? Dynamic Contrast Ratio (DCR) auto adjusts the brightness of the screen so users can see the darker areas of the displayed content in more depths.
more layers and details of the picture, especially in the darker areas. Please note when DCR is on, DCB will be disabled. DCR Demos: Disclaimer: DCR aftereffects are subject to the resolution and quality of the display content, hence may look different than the above illustrations. Function Control Illustration Luminance Brightness Contrast Eco mode Adjust Range 0-100 0-100 Standard Description Backlight Adjustment Contrast from Digital-register.
Gamma DCR Image Setup Clock Focus H.Position V.Position Color Temp.
Position Bright Frame OSD Setup H.Position V.Position Timeout Language Extra Input Select Auto Config Reset DDC-CI Information H. position V.
11. Click on the 'Finish' button then the 'Close' button. If you can see the 'Digital Signature Not Found' window, click on the 'Yes' button. Windows ME 1. Start Windows® Me 2. Click on the 'Start' button, point to 'Settings', and then click on 'Control Panel'. 3. Double click on the 'Display' Icon. 4. Select the 'Settings' tab then click on 'Advanced...'. 5. Select the 'Monitor' button, then click on 'Change...' button. 6.
9. Click the 'Next' button. 10. Wait few minutes for installing the driver, and then click 'Close' button. 6. Technical Support Frequently Asked Questions Problem & Question • Power LED Is Not ON • No Plug & Play • Possible Solutions Make sure the power button is ON and the Power Cord is properly connected to a grounded power outlet and to the monitor. In order for the Plug & Play feature of the monitor to work, you need a Plug & Play compatible computer & video card.
7. Product Information Specifications Model number 203Vw+ Driving system TFT Color LCD Size 508mm ( 20") Pixel pitch 0.258mm(H) x0.258mm(V) LCD Panel Video R, G, B Analog lnterface & Digital Interface Separate Sync. H/V TTL Display Color 16.7 million Colors Dot Clock 146.25 MHz Horizontal scan range 31 kHz - 80 KHz Horizontal scan 433.44 mm Size(Maximum) Vertical scan range 56 Hz - 75 Hz Vertical scan Size(Maximum) 270.
Operating Non-Operating 0~ 3000m (0~ 10000 ft ) 0~ 5000m (0~ 15000 ft ) EPA ENERGY STAR® ENERGY STAR® is a U.S. registered mark. As an ENERGY STAR® Partner, AOC International (Europe) GmbH has determined that this product meets the ENERGY STAR® guidelines for energy efficiency.
2 3 4 5 6 7 8 9 10 11 12 13 14 15 Pin No. 1 2 3 4 5 6 7 8 Video-Green Video-Blue N.C. Ground GND-R GND-G GND-B +5V Detect Cable N.C. DDC-Serial data H-sync V-sync DDC-Serial clock Signal Name TMDS Data 2TMDS Data 2+ TMDS Data 2/4 Shield TMDS Data 4TMDS Data 4+ DDC Clock DDC Data N.C. Pin No. 9 10 11 12 13 14 15 16 Signal Name TMDS Data 1TMDS Data 1+ TMDS Data 1/3 Shield TMDS Data 3TMDS Data 3+ +5V Power Ground(for+5V) Hot Plug Detect Pin No.
8. Warranty Statement Warranty Statement LIMITED THREE-YEAR WARRANTY* AOC Color Monitors sold within Europe AOC International (Europe) GmbH warrants this product to be free from defects in material and workmanship for a period of Three (3) years after the original date of consumer purchase. During this period, AOC International (Europe) GmbH will, at its option, either repair the defective product with new or rebuilt parts, or replace it with a new or rebuilt product at no charge except as *stated below.
• • • • • • • • Shipping or improper installation or maintenance Misuse Neglect Any cause other than ordinary commercial or industrial application Adjustment by non-authorized source Repair, modification, or installation of options or parts by anyone other than an AOC Authorized Service Center Improper environment Excessive or inadequate heating or air conditioning or electrical powers failures, surges, or other irregularities This limited warranty does not cover any of the product firmware or hardware th
