Six USB Connectors
Provides three ports, six USB connectors with transfer rates at high speed of 480Mbps for USB interface devices, such as
mouse, keyboard, modem, scanner, etc.
IEEE 1394 (AK79G-1394 and AK79D-1394 only)
This motherboard comes with great function of IEEE1394 which provide transfer data rate up to 400Mbps.
1MHz Stepping CPU Frequency Adjustment
Provides “1MHz Stepping Frequency Adjustment” function in the BIOS. This magic function allows you adjust CPU FSB
frequency from 100~200 by 1MHz stepping, and lets your system can get maximum performance.
Power Management/Plug and Play
Supports the power management function that confirms to the power-saving standards of the U.S. Environmental Protection
Agency (EPA) Energy Star program. It also offers Plug-and-Play
, which helps saving users from configuration problems, thus
making the system much more user-friendly.
Hardware Monitoring Management
Supports CPU or system fans status, temperature and voltage monitoring and alert, through the on-board hardware monitor
module and AOpen Hardware Monitoring Utility.
