DESTINY 4100 Installation Instructions K1106 3/98 Downloaded from - http://www.guardianalarms.
Dear Dealer/Installer: We appreciate your decision to use the Destiny 4100 for this installation. As a division of the Pittway Corporation and member of the ADEMCO Security Group, we are proud to provide you with equipment made by ADEMCO, the world’s largest alarm manufacturer. The manufacturing facility is ISO 9001 certified and contains the most modern automated manufacturing and testing equipment in the industry. The most important design resource for apex is our dealers.
Software Revisions Current software at time of printing: Control Panel: 1.00 Bridge (Gate): 1.02 EXP-8: 1.01 RK36 LED Keypad: 4.
Table of Contents Specifications................................................................................................................................ 6 Items Included With the Control Panel .......................................................................................... 8 Inserting the Cabinet Lock ............................................................................................................ 9 Mounting the Control Board .....................................................
Specifications Electrical: Voltage Input: 16.5 VAC 40 VA from supplied transformer External Speaker: 10 Watt minimum, 8Ω horn type - Ademco 713 or equivalent. Total speaker load must be between 4Ω and 16Ω. Internal Speaker: Speaker supplied in all compatible keypads. For stand-alone operation 10 Watt minimum, 8Ω - Ademco 747 or equivalent. Total speaker load must be between 4Ω and 16Ω. For UL installations use a UL residential fire listed speaker. Auxiliary Power Output: 13.5VDC, 1.
Speaker Output: 10 Watt internal siren driver with full speech 10 Watt external siren driver with full speech Designed for use with 8Ω, 10 watt minimum speakers. Total impedance for either driver not to drop below 4Ω For UL installations use a UL residential fire listed sounder.
Items Included With the Control Panel: Please examine the contents of the shipping box for the following items: 1 1 1 1 1 1 8 - Control Panel - 16.5 VAC 40 VA Transformer - Auxiliary Output Harness - Microphone Harness - Installation Manual - Owners Manual 1 9 3 1 1 2 - Lock, key, and retaining clip - 4.
Inserting the Cabinet Lock 1. Remove the cabinet door Retainer Clip (Note Position) 2. Remove the lock knockout from the control cabinet door. Insert the key into the lock. Position the lock in the hole making certain that the latch will make contact with the latch bracket when the door is closed. 3. Hold the lock steady, and insert the retainer clip into the retainer slots. Position the clip as illustrated in order to permit easy removal. Retainer Slot Mounting the Control Board 1.
Phone U/D Status Wiring Diagram 10 POWER Mic Inputs Program + 1 2 3 Com Com J2 + 5 VDC Microphone 1 Signal Microphone 2 Signal Microphone 3 Signal Shield Shield 2-Way Volume Adjust Siren J5 Note: Auxiliary Outputs are pull-to-ground on activation at 100mA per pin. Total Current can not exceed 500mA.
Wiring Notes Grounding: Ground the panel to the "com" on far left terminal block as shown in Wiring Diagram on previous page. UL recommends attaching the system ground to a cold water pipe, 16ga. at 15 feet. Although cold water pipes have been the standard for earth ground, it is very common in modern construction that a cold water pipe does not provide an adequate ground due to the extensive use of PVC and other styles of "plastic" tubing.
System Terminals House Phones: The R1 and T1 terminals provide telephone service to the house if the installation contains an RJ-31X terminal block for true phone line seizure. Telephone Company: The incoming telephone service is wired through an RJ-31X jack to the R and T terminals on the control panel. If regular phone service is unavailable, the system will provide power and a distinct system tone to all in house phones.
Battery Leads: Connect the red lead to the + battery terminal and the black lead to the - battery terminal. The battery is tested every 180 seconds to ensure it is present and charged. A low battery condition can be indicated at the keypad and/or communicated to the central station. Auxiliary Outputs: An auxiliary output wire harness is supplied for J5. There are 4 programmable output pins and 2 power pins. Pins 1-4 will provide a ground path when activated. Pins 5 & 6 supply +12V DC.
POWER LED: At the top right of the board is a red LED labeled "POWER" which is illuminated when the system is receiving power. STATUS LED: At the top right of the board is a green LED labeled "STATUS" which flashes to show the microprocessor is functioning. An incoming ring detection will cause this LED to flash very fast for the first ring.
Wiring an Input Using an End-of-Line Resistor 4.7KΩ 4.7KΩ Normally Closed Single E.O.L Resistor: Normally Open Traditional inputs are wired with a single end-of-line resistor. An open or short is treated as an open. A single end-of-line resistor is only effective if the resistor is placed after the last device wired in an input loop. This is the only suitable wiring method for smoke loops. 4.7KΩ 4.7KΩ 4.7KΩ Wiring an Input Using 2 End-of-Line Resistor Supervision 4.
Programming System options are contained in EEPROM. Each programmable section of memory has a 4 digit location and a three digit value. To reduce the amount of programming necessary, each location is supplied with a default value. The programming process can be simplified and the chances of programming errors can be reduced by obtaining a copy of the Windows 95 based PC software available from APEX, the BBS at 919-954-0318 or our web site at www.ademco.com/apex/apexhome.htm.
Quick Start Keypad connection: Connect a hardwire keypad to the keypad terminals on the control board, be certain to properly match the colors as follows: Black to BLK, Red to RED, Green to GRN, White to WHT. Speaker connection: Connect the violet keypad speaker leads to the INT and COM terminals on the control board. Power connection: Connect the power transformer to the AC terminals on the control board and plug the transformer into an unswitched 120 VAC outlet.
Using This Manual: Automated Locations: Automated Location prompt for specific information and automatically record the appropriate information into the correct locations. Value Locations: A documented location that contains a specific value (i.e. time, user number, etc.) Option Location: Most system options require a total of option values to be placed in a location. Example: Options - Enter Total Location Value .........................................................................................
System Setup Hardware Device Types TROUBLE AC Power Low Battery Communicator System Zone Assignments (Assignments may not be changed) System Board Inputs 1-8 Zone 1-8 Two Wire Smoke Loop Zone 9 Wireless Transmitters Zones 10 - 23 Portable Transmitters Zones 24 - 25 System Keypads Zone 26 Local Phone Panic Zone 27 Phone Line Monitor Zone 28 Monitor Trouble Conditions Zone 29 19
Programming Zones The device types for each zone on the Destiny 4100 are predefined. The device assignments are fixed and may not be modified.
Zones 1 - 8: System Controller At default, all 8 system inputs are disabled. To enable a hardware input, enter a zone type in the zone type location. Example: To enable Zone 1 (Input 1) and assign it as an Exterior Instant, enter 0647,000 Generally, this is all of the programming necessary to activate a zone. There are 4 spaces in each zone record to note a zone description.
Zone 9: System Controller Two-Wire Smoke Loop At default, the two wire smoke loop is disabled. To enable the loop, enter 0775,006 (Zone type Fire). The word description is predefined as "Smoke Detector." This can be changed by altering the zone description for zone 9. Programming zone descriptions is covered at the end of this section.
Each of the 14 alarm point transmitters are defaulted as a supervised 5817 using loop 2. To adjust these settings, enter the correct total from the options below in the Loop Location. When transmitters are being used that only have one input, use loop 1. Loop Options Value Use Loop 1 ................................................................................................................... 001 Use Loop 2 ................................................................................................
Zones 18 - 23: Alarm Type Transmitters Continued Input Option Device Loop Zone Type Option 1 Option 2 Word 1 Word 2 Zone 18 Transmitter 9 Serial #: Location Default 1248 005 1245 130 0919 255 0915 080 0916 000 Word 3 Word 4 Input Option Device Loop Zone Type Option 1 Option 2 Word 1 Word 2 Zone 20 Transmitter 11 Serial #: Location Default 1272 005 1269 130 0951 255 0947 080 0948 000 Word 3 Word 4 Input Option Device Loop Zone Type Option 1 Option 2 Word 1 Word 2 Zone 22 Transmitter 13 Serial #: Locati
Portable Transmitters Type Description Value 5801 ................................... 4 button portable .............................................................. 008 5802 ................................... 1 button portable .............................................................. 016 5802 CP .............................. 1 button portable .............................................................. 017 5802 MN ............................ 1 button portable ....................................
Zone 26: System Keypads All keypad activations report as Zone 26. Keys and key combinations are fully programmable. Use the button function list (Zones 24-25) to change the functionality of the listed keypad inputs. The word description is predefined as "System Keypad." This can be changed by altering the zone description for zone 26. Programming zone descriptions is covered at the end of this section. Option 1 value 016 (report to central station) is the only Zone Option that applies to zone 26.
Zone 29: Monitor Trouble Conditions Option - A description of each option is available in the Glossary Location Value .................................................. * Duration for recognition of AC power loss (minutes) 0097 ....... 001 ....................................... * Monitor low battery and enable battery test (001 to enable) 0180 ....... 000 ............................................................................. * Communicator fail (001 to enable) 0181 .......
Automated Programming Locations Place system in RF field strength mode and speak serial number ........................................................ 9951 Exit RF field strength mode ................................................................................................................. 9950 Exit program mode ............................................................................................................................. 9899 Clear user codes 2-8 .....................................
Vocabulary Word Location Access ..................... 024 Account .................. 025 Alarm ....................... 222 Alert ......................... 026 Am ........................... 033 And .......................... 197 Appliance ................ 027 April ........................ 227 Are ........................... 028 Area ......................... 029 Armed ...................... 030 Attic ......................... 031 August ..................... 231 Away ....................... 032 B .......
System Times And Other Options System Time Options - A description of each time is available in the Glossary Units Location Default Entry delay 1 (Not to exceed 45 seconds in a UL installation) .............................seconds ....0080 ...... 020 _______ Entry delay 2 (Not to exceed 45 seconds in a UL installation) .............................seconds ....0081 ...... 020 _______ Exit delay (Not to exceed 60 seconds in a UL installation) ..................................seconds ....0082 ......
System Options - Group 1 Options - Enter Total - A description of each option is available in the Glossary Location Value ...................................................................................................................... Disarm before rearm 004 Mute external Speaker (external driver -off, internal driver - adjustable) ........................................ 008 Access code before arm .......................................................................................................
Monitor Trouble Conditions Option - A description of each option is available in the Glossary Location Value ....................................... * Monitor low battery and enable battery test (001 to enable) 0180 ....... 000 ............................................................................. * Communicator fail (001 to enable) 0181 .......
System Triggers Event Location Output Location Option Location Time ...................................... .......... ........... .......... ............ ...........005 Any alarm activation 0122 000 0188 010 0475 Burglary ......................................................... 0123 .......... 000 Fire ................................................................ 0124 .......... 000 Panic ............................................................. 0125 .......... 000 Silent Panic ....................
System Triggers Option Option - Enter Total Value Activation Action Do Nothing ................................................................................................................... 000 Turn Output Off ............................................................................................................ 001 Turn Output On ............................................................................................................ 002 Turn Output Off, Start Delay ...........................
Automated Event Memory Log Upload Choose upload days total Location Value ........................................................................................................................................... Sunday 001 Monday ......................................................................................................................................... 002 Tuesday .................................................................................................................................
Fail To Open (Disarm) / Fail to Close (Arm) Options - Enter Total Location Value ....................................................................................................................... Enable Fail to Open 001 Fail to Close - Verify Armed to AWAY ............................................................................................ 002 Fail to Close - Verify Armed to Home or Night ...............................................................................
Two-Way Digit Assignments This feature is not permitted in a UL installation Telephone Digit Default Function Location Default Value .............................. ................... 0 Exit 2-way by going to keypad mode or hanging up 0162 000 1 Microphone #1 On ................................................................................ 0163 ................... 001 2 Microphone #2 On ................................................................................ 0164 ...................
Ademco Contact ID Report Codes APEX Description Code Sent to Central Station ADEMCO Description Exterior instant .................................. E 131 Z ............................................ Perimeter burglary Exterior delay 1 ................................. E 134 Z ............................................ Entry/exit burglary Exterior delay 2 ................................. E 134 Z ............................................ Entry/exit burglary Interior instant ...........................
Dialer Options Options - Enter total Value ............................................................................................................... Dial Phone #1 001 Dial Phone #2 ............................................................................................................... 002 Enable two-way voice/listen in (Not permitted in a UL installation) .............................. 004 Dial alternate number if first choice fails .............................................................
Report Type Open (Disarm) Location Central Station Report Code ....................... 0359 ........ Dialer Option ............................................. 0409 ........ Open (Disarm) After Activation Central Station Report Code ....................... 0360 ........ Dialer Option ............................................. 0410 ........ Close (Arm) Central Station Report Code ....................... 0361 ........ Dialer Option ............................................. 0411 ........
Glossary of Terms Access code before arm: In this configuration, a full access code (arm/disarm code) must be entered to arm the system. Once armed, the system must be disarmed to allow a change from one arming mode to another. Alarm cut off and reset: The system provides for an automatic reset (cut off high volume tones and system reset) in the range of 1 to 255 minutes. Answer service override: For installations that use answering services provided by the phone company.
Button Functions: These are activations that are controlled by portable transmitters and/or key combinations on keypads. Silence Day Zone: Cancels a day zone and extended monitor activation. Speak Long Term Memory: The system maintains a long term alarm memory for all alert activations. This is useful for identifying zones that cause the system to go into alarm. The zone activations can be retrieved by entering a valid user code followed by the 8 key.
Bypass Mode: To bypass individual zones, enter a valid full function code followed by the 9 digit. The system will speak "BYPASSED MODE, ENTER ZONE NUMBER." Press a two-digit zone number (leading zero if necessary). The current bypass state of the zone is spoken. Pressing A toggles the bypass status (confirmed in speech). Pressing H exits bypass mode. To unbypass all bypassed zones, enter 00 as the two-digit zone number.
Clear Keypad Status: Under very unusual circumstances, a keypad may not receive a transmission from the control panel resulting in a status message not being cleared. This command clears all status messages at the keypad. Clear User Codes: This location will erase user codes 2 through 8. Delay Before Dial: For both phone numbers, the system will wait a programmed time period (1 to 255 seconds) after activation before dialing the central station.
Display Open at Keypad: Used to show when specified zones are open. Typically, all internal zones (PIR's, Smoke Detectors) are not programmed to show status at the keypad. This prevents constant STATUS light flashing. External zones (windows, doors) should be programmed to show status so the user is updated to all perimeter changes. Zones that are programmed not to show open at the keypad are not included in the monitor mode, unless extended monitor is used.
Enable Two-way Callback: For this option to be used, at least one activation must be programmed to enable twoway voice/listen-in with the central station. After the digital communication, with this option enabled, the system will hang up and wait for the programmed time in location 0461 for a call back from the central station. The dialer LED will blink while waiting for the return call.
There are two different levels or types of extended monitor, A and B. Locations 0177 and 0175 determine which zone types are to be monitored by each extended monitor type. Entering a full function user code followed by the digit 3 will place the system in extended monitor mode type A or enter the 4 digit for extended monitor type B. When entering extended monitor the system responds with "MONITOR ON" through the inside speaker. NOTE: You can only enter the extended monitor mode when the system is disarmed.
No Exterior Instant Exit Delay: When enabled, this option will eliminate the exit delay on all exterior instant zones following arming to either HOME or AWAY. No Program Mode: With this option set, the system will not enter program mode with the panel armed. Number of Activations for Auto-Bypass: Zones can be automatically bypassed, if the zone causes multiple activations within a specified time frame (reset each time the system is armed). The number of activations and time period are programmable.
Report Code: All events that initiate a communicator report are associated with a report code (based on zone type) that appears at the central station. Each report code can be defined for all report types except Contact ID. When Contact ID is used, no programming is required. The following abbreviations are used in the "Ademco Contact ID Codes" Chart: Z U E R Reporting Formats: - Zone (up to 3 digits) User number Event or open Restore or close Ademco Contact ID: A DTMF based reporting format.
Set Time and Date: After entering 9991 the system will prompt "Enter Eleven." The time, day, and date are entered in the following format HHMMWMMDDYY. HHMM - Military time, if the hour value is less than 10 use a leading zero. W - Day of the week: 1-Sun 2-Mon 3-Tue 4-Wed 5-Thr 6-Fri 7-Sat. MM - Month. Months less than 10 use a leading zero. DD - Date. Days less than 10 use a leading zero. YY - Enter the last 2 digits of the year.
Speak Phone Number: To confirm programmed phone numbers, Enter the appropriate 9000 location and the number will be spoken. Special dialing feature codes will be heard as follows: Dialing Feature Spoken As Dial * Star Dial # Pound Wait for second dial tone Tone 3 second pause in dialing sequence Pause Speak Pre-alarm: When this option is selected the system will repeat "ENTRY DETECTED" followed by a zone description during pre-alarm in place of a low volume siren tone.
Touch Tone / Pulse: This location determines the type phone service the panel uses for dialing. Program 000 for touch-tone or 001 for rotary. Track Activations: With this option enabled, each individual zone activation will be written to long term memory as opposed to only the zone activation that created the alarm. For example, the back door causes an activation, then a passive infrared zone detects motion and then the front door opens.
Disarm: Active when the panel is disarmed. The output is restored when the panel is armed. Access Code Entered: Output is activated when an access code is entered. There is not an event that restores the output , it is recommended to only use this trigger with channels programmed to automatically turn off. Alert: Activates the specified output during all alarm activations. The output is restored after the alert status is cleared from the keypad.
code is entered or the two-way callback time expires. If neither code option is selected, the system will be in listen-in mode when the phone is answered. Without the "0 exits to keypad mode" options selected, the central station will not have access to keypad mode. Two-way key functions: It is not recommended to alter the telephone digit assignments for two-way voice, however, to conform to some central stations this process may be necessary. To reassign the assignments, place a 001 in location 0161.
Day: When the system is not armed a Day zone will cause an Extended Monitor activation and can send a Day Zone Trouble report to the central station. When the system is armed a Day Zone will act like an Exterior Instant. A day zone extended monitor activation can be cancelled with the "Silence Day Zone" button function. Emergency: Emergency zones respond though inside speakers only. The alert consists of a pulsed tone followed by "ALERT, ALERT", and the up-to-four-word description of the zone.
Silent Panic: Silent panic zones respond by activating the communicator. An activation appears in system status, however, no audible indication is given. Step Arming: The arm/disarm zone type is used for momentary arming inputs such as a keyswitch or touchpad. Each time the zone is closed the system moves in order between the following stages. Starting with the system disarmed, the first momentary closure will arm the system to AWAY.
FEDERAL COMMUNICATIONS COMMISSION (FCC) PART 15 STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information: This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause Interference to radio and television reception.
INSTALLATION LAYOUT Early warning fire detection is best achieved by the installation of fire detection equipment in the location as follows: BEDROOM BEDROOM DINING ROOM KITCHEN BEDROOM Installing Company: ____________________________________ Telephone Number: ____________________________________ LIVING ROOM BEDROOM A smoke detector shall be located between the sleeping area and the rest of the house. - Refer to N.F.P.A. #74 Appendix B-1.1 thru B-10.
WARNING THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced wireless security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of reasons. For example: * Intruders may gain access through unprotected openings or have the technical sophistication to bypass an alarm sensor or disconnect an alarm warning device. *Intrusion detectors (e.g.
ADEMCO LIMITED WARRANTY Alarm Device Manufacturing Company, a Division Of Pittway Corporation, and its divisions, subsidiaries and affiliates (`Seller'), 165 Eileen Way, Syosset, New York 11791, warrants its products to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and service for 18 months from the date stamp control on the product or, for products not having an Ademco date stamp, for 12 months from date of original purchas
