APC-3228A Panel PC User Manual Release Date _ Revision Aug. 2012 ® 2012 Aplex Technology, Inc. V1.0 All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw APC-3228A User Manual URL: www.aplex.com.
Warning!___________________________________ This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions manual, it may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
Packing List Accessories (as ticked) included in this package are: □ AC power cable □ Driver & manual CD disc □ Other.___________________(please specify) Safety Precautions Follow the messages below to prevent your systems from damage: ◆ Avoid your system from static electricity on all occasions. ◆ Prevent electric shock. Don‘t touch any components of this card when the card is power-on. Always disconnect power when the system is not in use. ◆ Disconnect power when you change any hardware devices.
Table of Contents______________________ Warning!…………………………………………………………………………….……..….2 Disclaimer………………………………………………………………….…………………2 Packing List…………………………………………………………………………………..3 Safety Precautions…………………………………………………………………………..3 Chapter 1 1.1 1.2 1.3 1.4 1.5 1.6 Getting Started Specifications……………………………………..….……………………..6 Dimensions………………………………...………………………….......7 Installation of HDD………………….…………………………….……….8 Installation of PCI Add-on………..……………………………………..10 Brief Description…………………………………………………….
Chapter 5 Touch Screen Installation 5.1 Introduction to Controller Board..…………………………..……………81 5.2 Windows 2000/XP USB Driver Installation for 5000 Boards………..….81 Figures Figure 1.1: APC-3228A Dimensions……………………………………..…....7 Figure 1.2: Front View………………………………………………………...11 Figure 1.3: Rear View………………………………………………………..11 Figure 1.4: Panel mounting…………………………………………………..12 Figure 1.5: VESA mounting…………………………………………………..12 Figure 2.1: Mainboard Dimensions…………………………………..…….....13 Figure 2.
Chapter 1 System 1.1 Specifications Specs CPU APC-3228A Intel socket P, support Intel T3100 1.9GHz and up to Intel P8600 2.4GHz Processor Chipset Intel GM45 + ICH9M System Memory 2 x 204 Pin SO-DIMM, up to 8GB DDR 3 800/1066MHz FSB Display Size 1920x1080 Maximum Colors 16.7M Viewing Angle (Degree) H:170 / V:160 Luminance (cd/m²) 400 Backlight Lifetime 40,000 Hours Rating Front Panel IP65 Touch Screen Type Resistive Type (option) Outside I/O port 4 x USB 2.
1.2 Dimensions Figure 1.
1.3 Installation of HDD Step 1 There are 2 screws to deal with when Installing of HDD. Step 2 Loosen screw and draw the HDD bracket out as shown in the picture.
Step 4 Push into the HDD bracket as shown in the picture. Step 5 Tighten the 2 screws as shown in the picture. That’s how it should look after it has been installed.
1.4 Installation of PCI Add-on Step 1 There are 2 screws to deal with when enclosing or removing the chassis. Step 2 Now slide the addon into the PCI slot, making sure the golden part faces the slot. When the part that is interfaced together come into the right contact, slightly push the addon into the rail of the slot. Step 3 After sliding the addon into the PCI expansion slot, get the one screw as circled tightened to finish the connection.
1.5 Brief Description of the APC-3228A The APC-3228A is a high performance, compact and panel-mount industrial PC, which comes with a 21.5-inch (luminance of 400 cd/m²) TFT LCD. It is powered by an Intel Socket P Core 2 Duo Processor, up to Intel P8600 2.4GHz processor. The industrial panel PC also features one PCI expansion slot, three COM ports, four USB 2.0 ports, one 2.5” HDD, one CF slot internal for option, and 9~32V DC, etc.
1.6 Panel Mounting of the APC-3228A The APC-3228A panel PC is designed to be panel-mounted as shown in Figure 1.4. Just carefully place the unit through the hole and tighten the given 10 screws from the rear to secure the mounting. Figure 1.4: Panel mounting of the APC-3228A Figure 1.
Chapter 2 Hardware 2.1 Mainboard Figure 2.
2.2 Installations ASB-M801 is a Mini-ITX industrial motherboard developed on the basis of Intel GM45 and ICH9M, which provides abundant peripheral interfaces to meet the needs of different customers. Also, it features dual 1000M LAN port, 6-COM port and one Mini PCIE configuration. To satisfy the special needs of high-end customers, PC104+ port (capable of adjusting IO voltage) richer extension functions. The product is widely used in various sectors of industrial control. 2.2.
Figure 2.
1. DCIN: (5.08mm Pitch 1x3 Pin Connector),DC9V ~ DC32V System power input connector。 Power Mode AT (Default) 2. Pin# Power Input Pin1 DC+9V~32 V Pin2 Ground Pin3 PG Location : Location: DCIN (5.4.4.) ATX12V (5.4.5.) input DC9~32V output DC 12V Location: ATX (5.4.6.) NC ATX12V: (2x2 Pin Connector),DC12V System power output connector. 3. Pin# Power output Pin1 Ground Pin2 Ground Pin3 DC+12V Pin4 DC+12V ATX (option): (2.
signal,support ATX Power model. Reserved. 4. Pin# Signal Name Pin1 ATX PSON PIN2 ATX Ground PIN3 ATX 5VSB CPU1: (Socket P), installing the CPU Socket. 5. CPU_FAN1/SYS_FAN1: (2.54mm Pitch 1x3 Pin Header),Fan connector, cooling fans can be connected directly for use. You may set the rotation condition of cooling fan in menu of BIOS CMOS Setup. Pin# Signal Name 1 Ground 2 VCC 3 Rotation detection Note: Output power of cooling fan must be limited under 5W. 6.
7. CRT1: (CRT DB15 Connector ),Video Graphic Array Port, provide high-quality video output. they can not work at the same time for CRT1 and VGA1. 8. VGA1: (CRT 2.0mm Pitch 2X5 Pin Header), Video Graphic Array Port, Provide 2x5Pin cable to VGA Port, they can not work at the same time for CRT and VGA1. Signal Name 9. Pin# Pin# Signal Name CRT_RED 1 2 Ground CRT_GREEN 3 4 Ground CRT_BLUE 5 6 VGA_EN CRT_H_SYN C 7 8 CRT_DDCDAT A CRT_V_SYNC 9 10 CRT_DDCCL K INVERTER1: (2.
10. LVDS1: (1.25mm Pitch 2x20 Connector), For 18/24-bit LVDS output connector, Fully supported by Intel GM45 chipset, the interface features dual channel 18/24-bit output.
13. JCOM1: (2.0mm Pitch 2x3 Pin Header),COM1 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM1 port. JP3 Pin# 14. Function Close 1-2 COM1 RI (Ring Indicator) (default) Close 3-4 COM1 Pin9=+5V (option) Close 5-6 COM1 Pin9=+12V (option) COM1: (Type DB9),Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. COM1 port is controlled by pins No.
Pin# 16. Signal Name 1 DCD# (Data Carrier Detect) 2 RXD (Received Data) 3 TXD (Transmit Data) 4 DTR (Data Terminal Ready) 5 Ground 6 DSR (Data Set Ready) 7 RTS (Request To Send) 8 CTS (Clear To Send) 9 RI (Ring Indicator) COM5: (2.0mm Pitch 2X5 Pin Header),COM5 Port, standard RS232 ports are provided. They can be used directly via COM cable connection. Signal Name Pin# Pin# Signal Name DCD 1 2 RXD TXD 3 4 DTR Ground 5 6 DSR RTS 7 8 CTS RI 9 10 NC 17. JCOM6: (2.
Signal Name 19. Pin# Pin# Signal Name DCD 1 2 RXD TXD 3 4 DTR Ground 5 6 DSR RTS 7 8 CTS RI 9 10 JCOM6 select Setting USB4/USB5/USB6/USB7: (Double stack USB type A), Rear USB connector, it provides up to 4 USB2.0 ports, speed up to 480Mb/s. Each USB Type A Receptacle (2 Ports) Current limited value is 1.5A. If the external USB device current exceeds 1.5A, please separate connectors into different Receptacle. 20.
22. AUDIO: (2.0mm Pitch 2X6 Pin Header), Front Audio, An onboard Realtek ALC662 codec is used to provide high-quality audio I/O ports. Line Out can be connected to a headphone or amplifier. Line In is used for the connection of external audio source via a Line in cable. MIC is the port for microphone input audio. Signal Name 23.
ASB-M801B/EB：PCIEX2 connector in the Bottom. MODEL PC104+ / PCIEX2 ASB-M801T Top ASB-M801ET Top ASB-M801B Bottom ASB-M801EB Bottom 27. MPCIE1: (Socket 52Pin),mini PCIe socket, it is located at the top, it supports mini PCIe devices with USB2.0, SMBUS and PCIe signal. MPCIe card size is 30x30mm or 30x50.95mm. 28. LED1: LED STATUS. Green LED for Motherboard Standby Power Good status, Yellow LED for HDD status. 29.
USB11 30. USB11_N 33 34 PWR_LED- USB11_P 35 36 MIO_PSON Ground 37 38 Ground Ground 39 40 Ground Power Button MIO2: (DF13-40P Connector),Front panel connector.
Pin3: Pin5: USB01 OC-, “USB01_OC-“ Signal. USB23 OC-,“USB23_OC-“ Signal. Pin7+Ground: RESET Button, They are used to connect reset button. The two pins are disconnected under normal condition. You may short them temporarily to realize system reset. Pin6+Pin8: POWER on/off Button, They are used to connect power switch button. The two pins are disconnected under normal condition. You may short them temporarily to realize system startup & shutdown or awaken the system from sleep state.
SATA4 (option) IDE_CF 1 (option) 32. SATA_P1/SATA_P2/SATA_P3: (2.5mm Pitch 1x2 box Pin Header), Two onboard 5V output connectors are reserved to provide power for SATA devices. Pin# Signal Name 1 +DC5V 2 Ground Note: Output current of the connector must not be above 1A. 33. SATA1/SATA2/SATA3/SATA4: (SATA 7P), SATA Connectors, Four SATA connectors are provided, with transfer speed up to 3.0Gb/s. ASB-M801ET/EB: SATA1/SATA2/SATA3 drives supporting RAID 0 or RAID 1 function.
35. CPU SCREW HOLES: CPU FAN SCREW HOLES, Four screw holes for fixed CPU Cooler assemble. 36. H5/H6: MPCIE1 SCREW HOLES, H5 for mini PCIE card (30mmx30mm) assemble. H6 for mini PCIE card (30mmx50.95mm) assemble. 37. TB-522: ASB-M801 I/O Card, via a dedicated cable connected to ASB-M801 MIO1. LED2: CF Card LED status. S1: PWR BT: POWER on/off Button, They are used to connect power switch button. The two pins are disconnected under normal condition.
(Type DB9),I/O serial port, it provides selectable RS422/RS485 serial signal output. RS422 Type (option) RS485 Type (option) Signal Name Pin# Pin# Signal Name 422_RX+ 1 1 NC 422_RX- 2 2 NC 422_TX- 3 3 485- 422_TX+ 4 4 485+ Ground 5 5 Ground NC 6 6 NC NC 7 7 NC NC 8 8 NC NC 9 9 NC Note: Use COM3 RS422 or RS485 Function, please enter BIOS CMOS Setup.
4 DTR (Data Terminal Ready) 5 Ground 6 DSR (Data Set Ready) 7 RTS (Request To Send) 8 CTS (Clear To Send) 9 RI (Ring Indicator) USB10,USB11: (Double stack USB type A), I/O USB connector, it provides up to 2 USB2.0 ports, speed up to 480Mb/s. Each USB Type A Receptacle (2 Ports) Current limited value is 1.5A. If the external USB device current exceeds 1.5A, please separate connectors into different Receptacle.
38. TXD4 13 14 DTR4- Ground 15 16 DSR4- RTS4- 17 18 CTS4- RI4- 19 20 5V_S5 5V_USB9 21 22 5V_USB1011 USB9_N 23 24 USB10_N USB9_P 25 26 USB10_P Ground 27 28 Ground Ground 29 30 Ground 5V_USB1011 31 32 PWR_LED+ USB11_N 33 34 PWR_LED- USB11_P 35 36 PS_ON- Ground 37 38 Ground Ground 39 40 Ground TB-520P1: TB-520P1 connect to ASB-M801T/ET PC104+ connector, PC104+ is located at the top, It provides one PCI slot. 39.
40. TB-520P1E1: TB-520P1E1 connect to ASB-M801T/ET PC104+ and PCIEX2 connector,PC104+ and PCIEX2 are located at the top, It provides one PCI slot and one PCIE slot. 41. TB-521P1: TB-521P1 connect to ASB-M801B/EB PC104+ connector, PC104+ is located at the Bottom, It provides one PCI slot. 42. TB-521P2: TB-521P2 connect to ASB-M801B/EB PC104+ connector, PC104+ is located at the Bottom, It provides two PCI slots.
43. TB-521P1E1: TB-521P1E1 connect to ASB-M801B/EB PC104+ and PCIEX2 connector,PC104+ and PCIEX2 are located at the Bottom, It provides one PCI slot and one PCIE slot. 44. TB-521P1E12: TB-521P1E12 connect to ASB-M801B/EB PC104+ and PCIEX2 connector,PC104+ and PCIEX2 are located at the Bottom, It provides one PCI slot and two PCIE slots.
45. TB-523: ASB-M801 I/O Card, via a dedicated cable connected to ASB-M801 MIO1 and MIO2. TB-523 Top： TB-523 Bottom： LED2: CF Card LED status.
S1: PWR BT: POWER on/off Button, They are used to connect power switch button. The two pins are disconnected under normal condition. You may short them temporarily to realize system startup & shutdown or awaken the system from sleep state. PWR LED: POWER LED status. COM3: (Type DB9),I/O serial port, it provides selectable RS422/RS485 serial signal output.
(option) RS485 Close: 5-7,8-10,9-11,12-14,16-18 (option) COM4: (Type DB9), I/O serial port, it provides selectable RS232/RS422/RS485 serial signal output.
USB11: (2.0mm Pitch 1x4 box Pin Header), I/O USB connector, it provides one USB2.0 port, speed up to 480Mb/s. Pin# Signal Name 1 5V_USB1011 2 USB11_N 3 USB11_P 4 Ground USB10 and USB11 current limited value is 1.5A. If the external USB device current exceeds 1.5A, please separate connectors into different Receptacle. CF: (CF Card socket), it is located at TB-523 and serves as an insert interface for Type I and Type II Compact Flash card. The operating voltage of CF card can be set as 3.3V or 5V.
GPIO_OUT3 9 10 GPIO_OUT4 MIO1: (DF13-40P) TB-523 MIO1 via a dedicated Y cable connected to ASB-M801 MIO1 and MIO2.
Chapter 3 BIOS Setup 3.1 Operations after POST Screen After CMOS discharge or BIOS flashing operation, the system will display the following screen for your further operation. Press F2 key to continue or F1 key to enter CMOS Setup. AMIBIOS© 2006 American Mega trends , Inc. BIOS Date: 09/06/11 23:32:27 Ver: 08.00.15 CPU : Genuine Intel(R) CPU 575 Speed : 2.00 GHz Press F11 for BBS POPUP Initializing USB Controllers. . 2013MB OK @ 2.00GHz Done. Auto-Detecting Pri Master..
3.2 BIOS SETUP UTILITY Press [Del] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit System Overview User [ENTER]，[TAB] AMIBIOS or Version [SHIFT-TAB] to Select a field : 08.00.15 Build Date : 12/12/11 ID Use[+] or [-] to : M801V003 configure system Time. Processor Genuine Intel(R) CPU Speed 575 @ 2.
System Date [Tue 09/06/2011] F10 ESC Save and Exit Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. System Time: Set the system time, the time format is: Hour : Minute : 0 to 23 0 to 59 Second : 0 to 59 System Date: Set the system date, the date format is: 3.4 Day: Month: Date: Note that the ‘Day’ automatically changes when you set the date.
V02.61 © Copyright 1985-2006 American Mega trends , Inc. 3.4.1 CPU Configuration BIOS SETUP UTILITY Advanced Configure advanced CPU settings Module Version: 3F.10 For UP platforms, Manufacturer : Intel For DP/MP serves, Genuine Intel(R) CPU 575 @ 2.00GHz Frequency :2.00GHz FSB Speed : 668MHz Cache L1 :32 KB Cache L2 :1024 KB Leave it enabled. It may use to tune Performance to the Specific application.
Execute-Disable Bit Capability: [Enabled] [Disabled] Intel(R) C-STATE tech: [Disabled] [Enabled] 3.4.
[Disabled] [Enhanced] Configure SATA as: [IDE] [RAID] [AHCI] SATA#2 Configuration: [Enhanced] [Disabled] Hard Disk Write Protect: [Disabled] [Enabled] IDE Detect Time Out : [35] [0] [5] [10] [15] [20] [25] [30] ATA(PI) 80Pin Cable Detection: [Host & Device] [Host] [Device] 3.4.3 Super IO Configuration BIOS SETUP UTILITY Advanced Configure Win627UHG Super IO Chipset Allow BIOS to Select Serial Port1 Address [3F8] Serial Port Base Serial Port2 Address [2F8] Address.
Serial Port3 Mode [RS-485] Serial Port4 Address [2E8] Serial Port4 IRQ [IRQ3] Serial Port5 Address [238] Serial Port5 IRQ [IRQ5] Serial Port6 Address [228] Serial Port6 IRQ [IRQ7] ← Select Screen ↑↓ Select Item +- Charge Field F1 General Help F10 ESC Save and Exit Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Serial Port3 Mode: COM3 Options: [RS485 ] [RS422] [RS422] for RS422 Mode [RS485] for RS485 Mode 3.4.
VSB :5.058 V VBAT :3.366 V Smart Fan Configuration Maximum CPU Temperature [60℃/140℉] Maximum PWM Duty for CPU Fan [60%] ← Select Screen ↑↓ Select Item +- Charge Field F1 General Help F10 ESC Save and Exit Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. System Temperature: Show you the current system temperature. CPU Temperature: Show you the current CPU temperature. CPUFAN Speed: Show you the current CPU Fan operating speed.
[Disabled] AMI OEMB table: [Enabled] [Disabled] Headless mode: [Disabled] [Enabled] [Chipset ACPI Configuration]: APIC ACPI SCI IRQ: [Disabled] [Enabled] High Performance Event Timer: [Disabled] [Enabled] 3.4.
3.4.7 MPS Configuration BIOS SETUP UTILITY Advanced MPS Configuration Select MPS MPS Revision [1.1] Revision ← Select Screen ↑↓ Select Item +- Charge Field F1 General Help F10 Save and Exit ECS Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. MPS Revision: [1.1] [1.4] 3.4.8 PCI Express Configuration BIOS SETUP UTILITY Advanced PCI Express Configuration Active [Disabled] State Power Enables/Disables -Management PCI Express L0s and L1 Link Power States.
V02.61 © Copyright 1985-2006 American Mega trends , Inc. Active State Power Management: [Disabled] [Enabled] 3.4.9 Smbios Configuration BIOS SETUP UTILITY Advanced Smbios Configuration SMBIOS SMI Wrapper Smbios Smi Support [Enabled] Support for PnP Func 50h-54h ← Select Screen ↑↓ Select Item +- Charge Field F1 General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Smbios Smi Support: [Enabled] [Disabled] 3.4.
+- Charge Field F1 General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Legacy USB Support: [Enabled] [Disabled] USB2.0 Controller Mode: [FullSpeed] [HiSpeed] BIOS EHCI Hand-Off: [Enabled] [Disabled] 3.5 Advanced PCI/PnP Settings This part describes configurations to be made on PCI bus system. PCI, namely Personal Computer Interconnect, is a computer bus that allows I/O device to operate nearly as fast as CPU in its own way.
IRQ3 [Available] ← Select Screen ↑↓ Select Item IRQ4 [Available] +- Charge Field F1 General Help IRQ5 [Available] F10 ESC Save and Exit Exit IRQ7 [Available] IRQ9 [Available] IRQ10 [Available] IRQ11 [Available] V02.61 © Copyright 1985-2006 American Mega trends , Inc.
[Enabled] PCI IDE BusMaster: [Disabled] [Enabled] OffBoard PCI/ISA IDE Card: Some PCI IDE cards may require this to be set to the PCI slot number that is holding the card. Auto:Works for most PCI IDE Cards. [Auto] [PCI Slot1] [PCI Slot2] [PCI Slot3] [PCI Slot4] [PCI Slot5] [PCI Slot6] IRQ3/4/5/7/9/10/11/14/15: [Available] [Reserved] Available: Specified IRQ is available to be used by PCI/PnP devices. Reserved: Specified IRQ is reserved for use by legacy ISA devices.
Boot Settings Configure Settings During System Boot ► Boot Setting Configuration ► Boot Device Priority ► Hard Disk Drives ← Select Screen ↑↓ Select Item Enter Go to sub screen F1 F10 ESC General Help Save and Exit Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Boot Setting Configuration： Configure Settings during System Boot. Quick Boot: [Enabled] [Disabled] Allows BIOS to skip certain tests while booting .This will decrease the time needed to boot the system.
[Off] Wait For ‘F1’ If Error: Wait for F1 key to be pressed if error occurs. [Enabled] [Disabled] Hit ‘DEL’Messgae Display : Displays “press” DEL to run Setup in POST. [Enabled] [Disabled] Interrupt 19 Capture: Enabled: Allows option ROMs to trap interrupt 19. [Disabled] [Enabled] Boot Device Priority: Specifies the Boot Device Priority sequence. Hard Disk Devices : Specifies the Boot Device Priority sequence from available Hard Drives. 3.
← Select Screen ↑↓ Select Item Enter Charge F1 General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Change Supervisor Password: Install or Change the password. Change User Password: Install or Change the password. Password Check: [Setup] [Always] Setup: Check password while invoking setup. Always: Check password while invoking setup a well as on each boot.
in Security Option of Advanced BIOS Features. If Security Option is set to System, you will be requested to enter the password before system boot and when entering BIOS setup; if Security Option is set to Setup, you will be requested for password for entering BIOS setup. 3.
Memory Remap Feature [Enabled] PCI MMIO Allocation: 4Gb To 3072MB Remapping of Memory [Disabled] Physical memory Hole Over lapped PCI Memory Above the total DISABLE: Do not allow Initate Graphic Adapter [PCI/IGD] IGD Graphics [Enabled ,64MB] Mode IGD GTI Graphic smemory size mode,2MB] remapping of memory Select [No VT PEG Port Configuration ► Video Function Configuration ← Select Screen ↑↓ Select Item +- Charge Field F1 General Help F10 Save and Exit ESC Exit V02.
Video Function Configuration: BIOS SETUP UTILITY Chipset Video Function Configuration Options DVMT Mode Select Mode] [DVMT DVMT/FIXED [256MB] Memory Boot Fixed Mode DVMT Mode Display Device [VBIOS-Default] Flat Panel Type [1024x768 18bit 1c] Backlight [VBIOS-Default] Control Support ← Select Screen ↑↓ Select Item Backlight Control Level [Level 8] +- Charge option Backlight Control Mode [DC] F1 General Help Backlight [VBIOS-Default] Image Adaptation F10 ESC Save and Exit Exit
[HDMI] [CRT + HDMI] [LVDS] [CRT + LVDS] Flat Panel Type: [1024x 768 18bit 1ch] [640x480 18bit 1ch] [800x480 18bit 1ch] [800x600 24bit 1ch] [1280x800 18bit 1ch] [1366x768 18bit 1ch] [1024x768 24bit 2ch] [1280x1024 24bit 2ch] [1440x900 24bit 2ch] [1600x900 24bit 2ch] [1680x1050 24bit 2ch] [1920x1080 24bit 2ch] Backlight Control Support [VBIOS-Default] [Both BLC & BIA Disabled] [BLC Enabled] Backlight Control Control: [Level8] [Level0] [Level1] [Level2] [Level3] [Level4] [Level6] [Level7] [Level9] [Level10] [L
Note: Panel support PWM Function. Backlight Control Mode: [DC] [PWM] Backlight Image Adaptation: [VBIOS-Default] [BIA Disabled] [BIA Enabled at Level1] [BIA Enabled at Level2] [BIA Enabled at Level3] [BIA Enabled at Level4] [BIA Enabled at Level5] 3.8.2 South Bridge Configuration: BIOS SETUP UTILITY Chipset South Bridge Chipset Configuration USB Functions Options [12 USB Ports] Disabled 2 USB Ports USB2.
PCIE Port 2 PCIE Port 3 PCIE Port 4 [Auto] [Auto] [Auto] +- Charge Field F1 General Help PCIE High Priority Port [Disabled] ESC F10 Save and Exit Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. USB Functions: [12 USB Ports] [Disabled]， [2 USB Ports] [4 USB Ports] [6 USB Ports] [8 USB Ports] [10 USB Ports] USB 2.
Restore on AC Power Loss: [Power Off] [Power On] [Last Status] PCIE Ports Configuration: PCIE Port 0: [Auto] [Enabled] [Disabled] PCIE Port 1: [Auto] [Enabled] [Disabled] PCIE Port 2: [Auto] [Enabled] [Disabled] PCIE Port 3: [Auto] [Enabled] [Disabled] PCIE Port 4: [Auto] [Enabled] [Disabled] PCIE High priority Port: [Disabled] [Port 0] [Port1] [Port2] [Port3] [Port4] [Port5] PCIE Port 0 IOxAPIC Enabled: PCIE Port 1 IOxAPIC Enabled: APC-3228A User Manual 62
PCIE Port 2 IOxAPIC Enabled: PCIE Port3 IOxAPIC Enabled: PCIE Port4 IOxAPIC Enabled: PCIE Port5 IOxAPIC Enabled: [Disabled] [Enabled] 3.
(ESC key can be used for this operation) [OK] [Cancel] Discard Changes: Discard changes? (F7 key can be used for this operation) [OK] [Cancel] Load Optimal Defaults: Load Optimal Defaults? (F9 key can be used for this operation) [OK] [Cancel] Load FailSafe Defaults: Load FailSafe Defaults? (F9 key can be used for this operation) [OK] [Cancel] APC-3228A User Manual 64
Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows XP. The software and drivers are included with the motherboard. The contents include Intel chipset driver VGA driver LAN drivers Audio driver .NET framework 3.5 driver Installation instructions are given below.
4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1: Select Chipset from the list Follow the step-by-step installation process to install the driver.
APC-3228A User Manual 67
Click Finish, when the installation process is complete, the Setup Complete screen appears. See as picture.
4.2 Intel Graphics Media Accelerator driver To install the VGA drivers, follow the steps below to proceed with the installation. 1. Click Intel(R) GM45 Chipset Family Graphics Driver. Follow the step-by-step installation process to install the Graphics Media Accelerator driver.
APC-3228A User Manual 70
APC-3228A User Manual 71
Click FINISH; A Driver Installation Complete.
4.3 Intel 82574L LAN Device Driver To install the Intel R 82574L Gigabit LAN connect device driver, please follow the steps below. Select LAN from the list Follow the step-by-step installation process to install the LAN driver.
APC-3228A User Manual 74
Click FINISH; A Driver Installation Complete.
4.4 Realtek ALC662 HD Audio Driver Installation To install the Realtek High Definition (HD) Audio driver, please follow the steps below. Select Audio from the list Follow the step-by-step installation process to install the Realtek HD Audio driver.
Click FINISH; A Driver Installation Complete.
4.5 Microsoft .NET Framework 3.5 Service Installation To install the Microsoft .NET Framework 3.5 Service, please follow the steps below.
APC-3228A User Manual 79
APC-3228A User Manual 80
Chapter 5 Touch Screen Installation This chapter describes how to install drivers and other software that will allow your PenMount 6000 Controller Board to work with different operating systems. NOTE: PenMount USB drivers support up to 15 USB controllers. 5.1 Introduction to Touch Screen Controller Board PenMount 6300 USB control board is a touch screen control board designed for USB interface and specific for 4, 5, 8-wire touch screens.
5.2.1 Installing Software If you have an older version of the PenMount Windows 2000/XP driver installed in your system, please remove it first. Follow the steps below to install the PenMount DMC6000 Windows 2000/XP driver. 1. Please make sure your PenMount 6000 device had plugged in advance. If your device uses RS232 interface, please plugged in before the machine is turned on. When the system first detects the controller board, a screen appears that shows “Unknown Device”. Do not use this hardware wizard.
3. A License Agreement appears.
4. Ready to Install the Program. Click “Install” 5.
6. The “Install Shield Wizard Completed” appears. Click “Finish”.
5.2.2 Software Functions Upon rebooting, the computer automatically finds the new 6000 controller board. The touch screen is connected but not calibrated. Follow the procedures below to carry out calibration. 1. After installation, click the PenMount Monitor icon “PM” in the menu bar. 2. When the PenMount Control Panel appears, select a device to “Calibrate.
Advanced Calibration Advanced Calibration uses 4, 9, 16 or 25 points to effectively calibrate touch panel linearity of aged touch screens. Click this button and touch the red squares in sequence with a stylus. To skip, press ESC’. Command Calibration Command call calibration function. Use command mode call calibration function, this can uses Standard, 4, 9, 16 or 25 points to calibrate E.g. Please run ms-dos prompt or command prompt c:\Program Files\PenMount Universa Driver\Dmcctrl.
NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: 3.Come back to “PenMount Control Panel” and select “Tools” then Click “Advanced Calibration”.
Select “Device” to calibrate, then you can start to do “Advanced Calibration”. NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy.
Setting APC-3228A User Manual 90
About This panel displays information about the PenMount controller and driver version.
Multiple Monitors Multiple Monitors supports from two to six touch screen displays for one system. The PenMount drivers for Windows 2000/XP support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit. The PenMount control boards must be connected to the computer COM ports via the RS-232 interface.
3. Touch each screen as it displays “Please touch this monitor. Press ‘S’ to skip” Following this sequence and touching each screen is called mapping the touch screens. 4. After the setting procedure is finished, maybe you need to calibrate for each panel and controller NOTES: 1. If you used a single VGA output for multiple monitors, please do not use the Multiple Monitors function. Just follow the regular procedure for calibration on each of your desktop monitors. 2.
Tools Draw Tests or demonstrates the PenMount touch screen operation. Advanced Calibration Enable Advanced Calibration function Right Button Icon Enable right button function. The icon can show on Desktop or System Tray (menu bar).
PenMount Monitor Menu Icon The PenMount monitor icon (PM) appears in the menu bar of Windows 2000/XP system when you turn on PenMount Monitor in PenMount Utilities. PenMount Monitor has the following function PenMount Rotating Functions The PenMount driver for Windows 2000/XP supports several display rotating software packages.
Windows Me/2000/XP support display rotating software packages such as: • Portrait’s Pivot Screen Rotation Software • ATI Display Driver Rotate Function • nVidia Display Driver Rotate Function • SMI Display Driver Rotate Function • Intel 845G/GE Display Driver Rotate Function Configuring the Rotate Function 1. Install the rotation software package. 2. Choose the rotate function (0°, 90°, 180°, 270°) in the 3rd party software. The calibration screen appears automatically.
