18 -
PowerBook G4 (12-inch) Views
Screw Reference Chart - 2 of 2
DC-to-DC Board
922-5908 922-5916
922-5909 076-1031
922-5922
922-5928
922-5925
Heatsink, Inner Frame, Optical Drive, Inverter Board
Heatsink, Inner Frame Heatsink
Optical Drive Brackets
Optical Drive Brackets
Display Housing
5
10
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
0
5
10
0
922-5919
Display Module (Rear Hinge)
5
10
0
922-6411
Top Case
(Right Side, DVI model)
5
10
0
