Troubleshooting New Components Theory of Operation/Jumper Location J16 - 4
Jumper Location J16
The jumper block you place at location J16 configures the board
to work with different processor modules. Use the appropriate
jumper block, identified by color, for each processor module.
Refer to “Processor Module” in Take-Apart for instructions.
The jumper block is protected by a void-warranty sticker. End
users are not allowed to remove this jumper block. If the sticker
has been tampered with on a unit you receive for repair, do not
honor the service warranty on the system.
Processor Speed Jumper Color
233 Red
266 White
300 Black
