Troubleshooting Power Supply Verification/Verification Procedure - 12
1. Plug in a known-good power cord into the back of the com-
puter.
Note:
Do NOT power on the computer.
Note:
For the next steps, refer to Figure 1 on the next page to
identify the pins indicated.
2. Connect the black lead of the voltmeter to pin 16 of the power
supply connector. Connect the red lead of the voltmeter to pin
9 of the 20-pin power supply cable. The voltmeter should
measure approximately +5V.
If you do not measure +5V then re-check the voltmeter con-
nections and check for voltage again. If voltage is still not
present then replace the power supply; otherwise, continue on
to the next step.
If you DO measure +5V on pin 9, the power supply is likely
OK. Continue on to the next step for further verification.
