Ultra Wide SCSI Card Specifications
m Automatic termination
m Advanced Data Streaming Technology (ADS)
m RAID-ready
m Embedded RISC I/P processor
m Ultra SCSI connector: Fine pitch 68-pin “P”
m Flash ROM BIOS
m PCI 2.1 compliant
m Large command FIFO
m Supports disconnect/reconnect
m Asynchronous I/O support
m Multiple initiator support
m SCSI-3 tagged command queuing
m SCSI Manager 4.3 compatible
RAID Disk Volume Management Software
Certain Power Macintosh G3 configurations are supplied with RAID disk volume management
software. This software enables your hard disk drives to be striped or mirrored.
The RAID CD can be used as a startup disk. You can restart from it and use the RAID
application to initialize and stripe or mirror your hard disks. You can also use the RAID Installer
to place a copy of the RAID application on one of your hard disks.
To restart your computer from the RAID CD, insert the CD and hold down the C key while
you restart.
Refer to the documentation supplied on the RAID CD for full instructions on how to set up
and maintain RAID volumes.
4
