CK60 / CKS70 60cm / 70cm Electric Cooktop USER MANUAL
Dear Customer, Congratulations on purchasing your new product from Home Appliances. To register your Parts and Labour Warranty, some conditions apply, please refer to your warranty card for more details and contact our Customer Care team on: 1800 444 357 Our Customer Care Centre is there to ensure you get the most out of your appliance. Should you want to learn more about your product and how to use it to its best potential or tips on cleaning, please feel free to call us on the above number.
NOTE: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.
Content 1. Foreword ........................................................................ 3 1.1 Safety Warnings .......................................................................... 3 1.2 Installation ................................................................................. 3 1.3 2. 3. 4. 1.2.1 Electrical Shock Hazard .................................................. 3 1.2.2 Cut Hazard ................................................................... 3 1.2.
1. Foreword 1.1 Safety Warnings Your safety is important to us. Please read this information before using your cooktop. 1.2 1.2.1 Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. • Alterations to the domestic wiring system must only be made by a qualified electrician.
• Failure to install the appliance correctly could invalidate any warranty or liability claims. 1.3 1.3.1 Operation and maintenance Electrical Shock Hazard • Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician. • Switch the cooktop off at the wall before cleaning or maintenance. • Failure to follow this advice may result in electrical shock or death. 1.3.
always store safely and out of reach of children. • Failure to use caution could result in injury or cuts. 1.3.5 Important safety instructions • Never leave the appliance unattended when in use. Boilover causes smoking and greasy spillovers that may ignite. • Never use your appliance as a work or storage surface. • Never leave any objects or utensils on the appliance. • Do not place or leave any magnetisable objects (e.g. credit cards, memory cards) or electronic devices (e.g.
• • • • • • • • • • • • Ceramic glass. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential type environments; -bed and breakfast type environments.
understand how to install correctly and operate it. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference. 2. 2.1 Product Introduction Top View 1. Max. 1200 W zone 2. Max. 1800 W zone 3. Max. 1200 W zone 4. Max. 1800W zone 5. Glass plate 7. Control panel 2.2 Control Panel 1. Hot hob warning indicators 2. Power regulating controls 2.
power regulation with the mechanical controls. 2.5 • • Before using your New Ceramic Hob Read this guide, taking special note of the ‘Safety Warnings’ section. Remove any protective film that may still be on your ceramic hob. 2.6 Technical Specification Cooking Hob CK 60 / CK S70 Cooking Zones 4 Zones Supply Voltage 220-240V~ 50/60Hz Installed Electric Power 5500-6600W Product Size 590X520X55 D×W×H(mm) Building-in Dimensions A×B (mm) 560X490 Weight and Dimensions are approximate.
3.2 How to use 3.2.1 Start cooking Place a suitable pan on the cooking zone that you wish to use. • Make sure the bottom of the pan and the surface of the cooking zone are clean and dry. Adjust the power regulating control to the desired level to turn on the control 3.2.2 Finish cooking Turn the cooking zone off by turning the power regulating control to “OFF“ to turn off the control Beware of hot surfaces When the glass plate is hot, the hot hob warning indicator will light.
• below boiling point. Some tasks, including cooking rice by the absorption method, may require a setting higher than the lowest setting to ensure the food is cooked properly in the time recommended. 4.1.2 Searing steak To cook juicy flavorsome steaks: 1. Stand the meat at room temperature for about 20 minutes before cooking. 2. Heat up a heavy-based frying pan. 3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then lower the meat onto the hot pan. 4.
Remove these immediately with a fish slice, palette knife or razor blade scraper suitable for Ceramic glass cooktops, but beware of hot cooking zone surfaces: 1. Switch the power to the cooktop off at the wall. 2. Hold the blade or utensil at a 30° angle and scrape the soiling or spill to a cool area of the cooktop. 3. Clean the soiling or spill up with a dish cloth or paper towel. 4. Follow steps 2 to 4 for ‘Everyday soiling on glass’ above. Boilovers, melts, and hot sugary spills on the glass 6.
L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm) 590 520 55 51 560+4 490+4 50 mini +1 +1 Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm. A(mm) B(mm) C(mm) D E 760 50 mini 20 mini Air intake Air exit 5mm 8.
8.3 Cautions 1. The ceramic cooker hob must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The ceramic cooker hob shall not be mounted to cooling equipment, dishwashers and rotary dryers. 3. The ceramic cooker hob shall be installed such that better heat radiation can be ensured to enhance its reliability. 4. The wall and induced heating zone above the work surface shall withstand heat. 5.
1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. 2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts. 3. The installer must ensure that the correct electrical connection has been made and that it complies with safety regulations. 4. The cable must not be bent or compressed. 5.
