Examples of printing
CL142 CL059 CL058
CL076 CL080 CL141
H8600VB ---
T8600VB ---
H8600VB ---
T8600VB ---
H8660VB ---
T8660VB ---
T8653VB ---
H8630FB ---
T8630FB ---
H8653VB ---H8650VB ---
T8650VB ---
Finish
Matt finish only.
Colour
Call sales for custom colours.
A full range is available for large orders.
Legend printing
Select from the examples or call sales for
custom legend.
Lamp voltage
Call sales for details of available voltages.
Blanking plate A8634FB
Dummy unit to fill unused panel holes.
Single pole size only.
Protective covers
L167 for SP
L180 for DP
(designed to IP65)
Snap on to bodies with V rocker or F lens, this
reduces maximum acceptable panel thickness
to 2.2mm.
Single Pole options
Most switches shown can have single pole
switching in double pole bodies.
15
rocker
switches
BODY
B Single pole
Panel cut-out Bezel
Single Pole dimensions for snap-in fixing
Panel thickness Dimension X
0.75-1.24 19.1/19.2
1.25-1.99 19.3/19.4
2.00-3.00 19.7/19.8
B (Double Pole) with terminal barrier
BC (Double Pole) w/o terminal barrier
Panel cut-out Bezel
Double Pole dimensions for snap-in fixing
Panel thickness Dimension X
0.75-1.24 19.1/19.2
1.25-1.99 19.3/19.4
2.00-3.00 19.7/19.8
DIMENSIONS (mm)
Single pole Double pole
5.8
12.5
2.0
7.4
7.0
7.0
OPTIONS
21.0
15.0
X
12.9
21.0
24.0
X
21.9
Terminals shown
are “H” 4.8 push on type
For 8620 and 8670 dimensions see page 16
5.8
19.8
to barrier
2.0
12.5
T
7.0
7.0
Terminal spacing
10.2 between pole centres
Cut-outs must be punched in the direction of insertion
