Operation Manual

7
GB
6.3.5 - Set point override by telephone control TYPHONE 500
• Only in heating mode (do not operate in cooling mode).
The user can:
- know the ambient temperature of zone 1,
- know the current set point temperature of zone 1,
- send a common override set point for zone 1 and 2.
During override, zone 1 and 2 operate in Comfort mode with
the new temperature set point.
This override is indicated by an index on the display.
Any action on the rotary knob deactivates the override.
Note: This function is possible only after entering the password
(given by the installer) by means of the phone keyboard.
6.4 - DOMESTIC HOT WATER PREPARATION (DHW)
• If installed - Activated according to the type of installation
• Available on installations 1 zone heating only (No cooling).
• Function activated during installation. Actuates the heat pump, in a cyclic way, for an
adapted DHW preparation tank pre-heating.
• A running DHW cycle can be stopped by setting the system to “OFF” (Then start it again
in the selected function).
• Out of the heating season, it is possible to activate this DHW function by selecting the cool
mode (=“Summer”). At that time, message “DHW” is appearing on the display.
6.5 - TIME AND DATE ADJUSTMENT
New current set
point.
Phone comfort
override index
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1
2
3
4
5
6
7
Set the
knob
to
The current
day flashes
Select the desired
day and validate by
pressing OK
Set the hour
using + or - and
validate by
pressing OK
Set the minutes
using + or - and
validate by
pressing OK
0h 2 4 6 8 10 12 1416 1820 2224
1
2
3
4
5
6
7
0h 2 4 6 8 1012141618202224
1
2
3
4
5
6
7
Set the
knob on
PROG Z1
The 1
st
time slot
flashes
Validate and continue
to the next day.
Repeat the procedure
for each day.
Repeat the
procedure for
each time slot
Ex.: Comfort
from 7h to 9h,
from 12h to 14h,
from 19h to 23h
6.6 - PROGRAMMING
To modify the programming for zone 2 (if this one is activated), set the knob to and
repeat the operations above
6.7 - STOP
1 h comfort
1 h reduced
Set the
knob to
