Index CONTENTS ..................................................................................................................................................4 GENERAL INFORMATION ......................................................................................................................6 CARE AND MAINTENANCEYOUR PHONE .........................................................................................6 YOUR PHONE ............................................................................
CALL RECORD ...............................................................................................................................22 Missed calls......................................................................................................................................22 Call duration ...................................................................................................................................22 SETTING ..............................................................
EMERGENCY CALLS ....................................................................................................................45 Contents Your phone • Keys and connectors • Standby mode Getting started • Installing the SIM card and the battery • Charging the battery • Switching the phone on and off Call functions • Making a call • Answering or rejecting an incoming call • Call waiting • Handling more than one call Menu functions 1.
• • • • Speed dial Memory status Copy all Delete all 3. Call record • • • • • Missed Received Outgoing Clear call Call duration 4. Setting • • • • • • • • Alarm Time & Date Melody Display Phone setting Call setting Security Reset all 5. Profile • • • • Normal Meeting Outdoor My profile 6. Extras • • • • • Calendar Calculator Stopwatch Time countdown Picture editor 7. Game 8.
General information Care and Maintenance 6
Your phone Keys and connectors— Side key • During a call, adjusts the earpiece volume. • In standby mode, the keys adjust the ring volume. • To reject an incoming call, press the side key twice. Earpiece Side key Display Soft key Four way Left soft key ● Talk key ● Yes key • The current functions are displayed in the bottom line of LCD. The soft key display as shortcut to access the sub menu.
Standby mode In the main display : Show the signal strength of the cellular network at current location. : Shows the battery charge level. : When your phone received one or several messages. : When all your calls are diverted to a specified number. : When the vibrate indicator is switched on. : When the alarm clock is switched on. : When the phone does not ring at an incoming call or message. : When you miss the incoming call. : Keypad lock : When use of your phone when you are outside your home area.
Getting started Installing the SIM card and the battery You need to insert the SIM card and charge the battery before using the phone. • Keep all miniature SIM cards out of the reach of small children. • Be careful to handle, insert or remove the SIM card since the SIM cart and its contacts can easily be damaged by scratched or bending. • Before installing/removing the SIM card, always make sure that the phone is switched off and then remove the battery. 1.
Charging the battery You must fully charge the battery before using your phone for the first time. 1. Connect the lead from the travel adapter to the socket on the bottom of your phone. (A) 2. Connect the charger to an AC wall outlet. 3. It can take 5-15 minutes before a charging icon is shown in the display. 4. Disconnect the charger from the phone by pressing the tabs on side of the connector and pulling the connector out.
1.Press and hold key. 2.When the sub menu pops up in screen, select keypad lock, press Select. To unlock the keypad 1. Press and hold key. 2. Press OK to release keypad lock Automatic keypad lock If no keys are pressed after 25 seconds, the keypad will be locked automatically. To switch the keypad lock or off 1. Press menu, choose Setting, press select. 2. Choose Phone setting, press select, choose Key lock, press select. 3. Choose On , Off or Auto, press OK.
Call functions This gives you information about the calling service that support in your phone. Making a call • In standby mode, key in the number, including the area code, press Note: Use . to move the cursor and use the soft key to delete the character. Making a call from the phone book 1. In the standby mode, Press “Names”, choose Search, press Select. Enter a name or press “Names“ to find a name, press 2. to call.
Handling more than one call You can handle up to two lines simultaneously. Making a second call 1. During a call, press Option, choose Hold, press Select. to make the second call. 2. Key in the numbers, press Note: You can only put one call on hold. Two calls on line To swap between the two calls • Press Swap. The first call is put on hold. To end the ongoing call and return the call on hold • Press .
Input method Before you start entering letters, you need to select the input method that you want to use when writing. To select input method 1. In Setting menu, choose Phone setting, press Select. 2. Choose Input select, press Select, choose a selection, press . 3. Press OK to exit the menu. To Changing case • Short press to change capital or lower-case letters. To Change input method • Long press to change the input method (T9Ab, ABC, abc, 123) To insert a space • Press to insert a space.
TUVÜÙ8 WXYZ9 + & @ / ¤ % $ €₤ ¥\ § ¿ ¡ 0 ΞΨΩ To activate keypad lock. To shift the case to lower-case and initial case. To activate Silent mode. To change text input. Predictive English input This predictive input method uses a built-in dictionary to recognize the most commonly used word for every sequence of key presses. 1. Press to 2. Press to view alternative words. 3. Press only once and a word is suggested. to enter a space a symbol.
Menu Structure Phone book You can save numbers and names in your phone or in SIM card. In addition, this phone allows you to store up to 100 numbers and names in phone memory. Names and numbers saved in the SIM card’s memory are indicated by . To save a phone number and a name 1. In standby mode, key in a number, press Options. 2. Choose Save, press Select, choose Save in SIM or Save in phone, press Select. 3. Key in the name and press OK to save number. To edit a number and a name 1.
Groups You can send a message to all members of a group at the same time by this setting. Before using this function, you need to edit name list in Group list of Phone Book. To add a name in a Group 1.In Phone book menu, choose Search, press Select. 2.Key in a name or press Names find a name in the phone book. 3.Press Detail, press Option, choose Group, press Select. 4.Choose a group, press OK. Group edition 1. In Phone book menu, choose Groups, Select. 2.
Memory status in the phone book This phone allows you to view the phone book data in SIM and Phone. 1. In Phone book menu, choose Speed Memory status, press Select. 2. Choose Memory status, press Select to view the status. Copy all You can copy and transfer your phone data from SIM to your phone (or from phone to SIM). 1. In Phone book menu, choose Copy all, press Select. 2. Choose Copy to phone or Copy to SIM, press Select.
Message Your phone services voice mail notification messages and text messages. Voice mail and short message service (SMS) are network service. Your phone also allows you to send and receive text messages contain pictures or melodies. A message with pictures was made up of several text messages. Therefore, sending message with pictures may cost more than sending one text message. Voice mail Your phone allows you to access your voice mailbox with a quick way if your operator provides this function.
To write messages Your phone allows you to write and edit text messages of up to 160 characters. 1. In Standby mode, press Menu, choose Message menu, press Select. 2. Message menu, choose Compose, press Select. 3. Key in the content, press Option, choose a selection, press Select. Note: To key in the content, you can see “Input method “ on Page 11. Note: To use picture message function, your network operator or service provider support is necessary.
Message setting Your phone allows you to set up default setting on the SMS feature. 1. In Standby mode, press Menu, choose Message menu, press Select. 2. In Message menu, choose a selection, press Select. Your phone provides the following setting selections for your option: •SMS center: This is the service center that allows you to save or change the number of your SMS center required when sending text messages.
Call Record Your phone can save information for missed, received and dialed calls, and the length and cost of your calls. Note: Once the call list exceeds the memory limitation, the oldest one is deleted. Missed calls Your phone allows you to view the last ten unanswered calls. You can also edit the number or delete the number from the call list. 1. In Call record menu, choose Missed, press Select. 2. Press Options and choose a missed call, press Select.
Setting Alarm This function allows you to set the alarm to ring at the time specified. The alarm clock works even when the phone is switched off. 1. In Setting menu, press Select. 2. Enter time, press OK. 3. Choose Once alarm or Repeat alarm, press Select. Time & Date setting This function allows you to view and change the time and date set in your phone. To set the Time This function allows you to change the time displayed, using the 12-hour or 24-hour format. 1. In Setting menu, choose Time & Date. 2.
Your phone provides the following date formats for your option: • mm/dd/yy • yy/mm/dd • dd/mm/yy Melody This function allows you to select ring signal volume, choose among different ring signals or compose your own ring signals. Ring setting 1. In Setting menu, choose Melody, press Select. 2. Choose Ring setting, press Select, choose a selection, press Select. 3. Choose a melody, press OK.
Your phone provides the following ring type selections for your option: • Ring only: The phone rings using the rinsing tone set in Melody Ring setting menu. • Vibrate only: The phone vibrates but doesn’t ring. • Ring & vibrate: The phone rings and vibrates both. • Vibrate first: The phone vibrates a few seconds then rings. Key tone This function allows you to select the keypad tone type when you press a key. 1.In Setting menu, choose Melody, press Select. 2.
To play or save your melody, press Options. To delete the notes • Short press Clear delete the notes one by one • Long press Clear soft key to delete all notes. Display setting Your phone allows you to set the display value to suit your preference. Wallpaper This feature allows you to set one of ten wallpapers in Main LCD display in standby mode. 1. In Setting menu, choose Display, press Select. 2. Choose a wallpaper, press OK. Contrast This function allows you to adjust the contrast of the LCD screen.
Phone setting Language This phone allows you to set a language for the display in this phone. 1. In Phone setting menu, press Select. 2. Choose a Language, press Select, choose a selection, press Select. Input select You can select input methods in this phone. 1. In Phone setting menu, press Select. 2. Choose Input select, press Select. 3. Choose an input method, press OK. Note: You can use to select the input methods for your preference.
Time alert This function allows you to set a time reminder during a call. 1. In Setting menu, choose Call setting, press Select. 2. Choose Time alert, press Select. 3. Choose a selection, press OK. Your phone provide the following time alert selections for your option: • Off • Each minute • User setting Notice: The minimum time for User setting is 30 seconds at least. Answer mode Your phone allows you to set an answer mode to answer incoming calls. 1. In Setting menu, choose Call setting, press Select. 2.
Call waiting This network service enables you to be informed when someone is trying to reach you during another call. 1. In Setting menu, choose call setting, press Select. 2. Choose Call waiting, press Select. 3. Choose Activate or Cancel, press Select. Note: Please refer to Call waiting on page26. Call divert You can set the call condition by which calls are diverted to another numbers. To Set call divert 1. In Setting menu, choose Call setting, press Select. 1. 2. Choose Call divert, press Select. 2. 3.
Security Phone and SIM card are protected against misuse by several security codes. PIN (4 to 8 digits) The PIN (Personal Identification Number) code protects your SIM card against unauthorized use. The PIN code is usually supplied with the SIM card. To activate or cancel PIN code 1. In Setting mode, choose Security, press Select. 2. Choose PIN, press Select. 3. Key in PIN number, choose on or off, press Select. Note: Your may need to obtain the password from your service provider.
Call barring This network service allows you to restrict your calls. To activate the call barring 1. In Setting menu, choose Security, press Select. 2. Choose Call barring, press Select. 3. Choose a selection, press Select. Your phone provides the following call barring selections for your option: Outgoing: All outgoing calls are not allowed to make. • Int’l calls (international calls): International calls are not allowed to make.
Change codes This feature allows you to change your current code to a new one. To change the code, you need to enter the current code before you can specify a new one. To change the codes 1. In Setting menu, choose Security, press Select. 2. Choose Change codes, press Select. 3. Choose a selection, press Select. Your phone provides the following code selections for your option: • Change PIN • Change PIN2 • Phone code Note: Please refer to Security on page 26.
Profile Your phone the following profiles to customize the alert to meet a certain environments. • Normal: Your phone is set in standard profile, which is the factory setting. • Meeting: Your phone ring volume is set to be low and key tone is switched off in meeting profile. • Silent: Your phone ring and key tone volume is switched off and the vibrator is activated in silent profile. • Outdoor: Your phone ring and key tone volume is set to be loud.
Your phone provides the following selections for your personalize option: • Silent • Incoming call • Message • Calendar • Alarm • Calendar • Ring volume • Ring or vibrate • Key tone • Accept list Note: You can change the profile to Silent or General quickly by long press * key.
Extras Calendar In the calendar you can add tasks for things such as reminders, meetings, birthdays that you need to make. The phone sounds an alarm tone when the set date expires. To make a note and reminder in Calendar 1.In Extra menu, choose Calendar, press Select. 2.Choose a day, press Select, choose Make a note, press Select. 4.Key in the note, press OK. 5.Choose None or reminder, press Select to save the note.
Calculator The calculator in this phone adds, subtracts, multiplies, divides, and converts currency values. To use the calculator • In Extra menu, choose Calculator, press Select. Your phone provides the following compose mapping s for your option: • : To change the symbol + (Add), - (Subtract) x (Multiply), ÷ (divide) • : To get the result. Note: This calculator has a limited accuracy rounding errors may occur, especially in long divisions.
Time countdown A set period elapses set in your phone, the last three seconds are indicated by a beep. At the end, a special beep sounds. To use the Time count down 1.In Extra menu, choose Time count down, press Select. 2.Enter the period, press OK. Picture editor Allow you to edit your own picture in your phone. To draw the picture 1. In Extra menu, choose Picture editor, press Select, 2. Press Option, choose Edit to start the drawing. 3. Press Option, choose Save to save the picture. To edit a picture 1.
Move the cursor down and left. Move the cursor down. Move the cursor down and right. Switch between black and white pen colors. Picture download management All pictures download save in this file that allow you to edit or to set to be wallpaper. 1.In Extra menu, choose Picture editor, press Select. 2.Choose a picture, press Select. 3.Press Options, choose wallpaper. Note: You can see the wallpaper set from this function in Setting/ display/ wallpaper function.
Game New game options 1. New game: Allow you to start a new game. 2. High scores: Show the highest scores. 3. Help: Show the play rule for the game. To record names in High score table to change the character. 1.Use to change the position. 2.Use 3.Use right softkey to complete the edit.
WAP service Your phones support Web Browser. You can obtain various services such as up-to date news, weather, sport, and other information as well as use e-mail and other Internet services. These services are designed and maintained by WAP service providers. The WAP service use Wireless Markup Language (WNL) on their WAP pages. You may not view the Internet web pages on your phone. Note: To activate WAP service, you may need to contact your service provider.
Push inbox: Your phone is able to receive service message sent by your service provider. Service messages are notifications of headlines or content, and they may contain address of a WAP service. To access the Push inbox in standby mode, when you received a service message, press Read. And the message is moved to the Push inbox when you exit the message. To Set the Push inbox 1. In WAP menu, choose Push inbox, press Select. 2. Choose Push inbox setting, press Select. 3. Choose On, press OK.
General information Battery care Your phone is powered by a rechargeable battery. • The battery can be charged and discharged hundreds of times but it will eventually wear out. When the operating time (talk-time and standby time) is noticeably shorter than normal, you should buy a new battery at the time. • Unplug the charger when not in use, and don’t leave the battery connected to a charger for longer than a week, since overcharging may shorten its lifetime.
Care and Maintenance Read this information before using your mobile phone. Your mobile phone is a highly sophisticated electronic device. When using your phone, battery, charger or any accessory, please read this first. Product care • Keep your mobile phone and all its parts out of young children’s reach. • Keep your mobile phone dry. • Avoid exposing your mobile phone to extreme hot or cold temperatures. • Avoid placing your mobile phone close to lit cigarettes, naked flames or any heat source.
Persons with pacemakers: • Should always keep the phone more than 20 cm (6 inches) from their pacemaker when the phone is switched on; • Should not carry the phone in a breast pocket; • Should use the ear opposite the pacemaker to minimize the potential for interference. • If you have any reason to suspect that interference is taking place, switch off your phone immediately. Hearing aids Some hearing aids might be disturbed by mobile phones.
RF energy may affect some electronic systems in motor vehicles such as car stereo, safety equipment etc. in addition, some vehicle manufacturers do not allow use of mobile phones, unless the installation is supported by a handsfree kit with an external antenna, in their vehicles. Check with your vehicle manufacturer’s representative to be sure that your mobile phone will not affect the electronic systems in your vehicle.
FCC Regulations: zThis mobile phone complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. zThis mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Regulations: zThis mobile phone complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. zThis mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
4RF Exposure Information (SAR) This model phone meets the government’s requirements for exposure to radio waves. This phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.
