1. DESCRIPTION AND DATA
DESCRIPTION
Designed to oer the best possible performance at the lowest possible cost, the Armasight Prime DC
is an exceptional, digital night vision monocular. Whether you choose to use it for camping, hunting,
boating or security, the Armasight Prime DC will allow you to look out into the night and unveil the
nocturnal world hiding in the darkness.
Available with either 4x or 6x magnications, the Armasight Prime DC is the absolute latest in the entry
level Digital night vision based on the high sensitivity CCD array. Color LCD display even allows for low
color saturation digital output. Compact and lightweight, this exceptional digital night vision monocu-
lar outperforms most other devices in its class.
FEATURES
4x or 6x magnication
–
High sensitivity CCD array
–
Color LCD display
–
Adjustable gain/brightness control
–
Built-in infrared illuminator
–
Compact and lightweight
–
Water and fog-resistant
–
Limited Two-Year Warranty
–
SPECIFICATIONS
Item Prime DC 4X Prime DC 6X
Sensor Type CCD CCD
Magnication 4x 6x
Objective Lens (mm) 42 52
Field of view (°) 12 8
Focus range (m) 2 to innity 5 to innity
Diopter adjustment (dpt) +5 to -5 +5 to -5
Exit pupil diameter (mm) 4 4
Eye relief (mm) 12 12
Power Supply
CR-123 Lithium (1) 3V CR-123 Lithium (1) 3V
Battery life - IR O (hour) up to 2.5 up to 2.5
Tripod mount Yes Yes
Lens material glass glass
Operating temperature (°C) -30 to +50 -30 to +50
Dimensions (LxWxH, mm/in) 180 x 80 x 60 / 7.1 x 3.1 x 2.4 200 x 80 x 60 / 7.9 x 3.1 x 2.4
Weight (g/lbs) 500 / 1.1 550 / 1.2
* Armasight reserves the right to modify these specications at any time without notice
