5.3. Operation'mode'
'
Q5HAD9C)
In STBY the amplifier is in bypass-mode and your transceiver is directly connected to the
antenna. Maximum allowed power in bypass mode is 100 Watts! Passing RF power is
measured with analog wattmeter only. It is not displayed if PA is either in standby mode
or turned OFF.
'
'
