Installation Instructions

The door jambs reinforce the door
opening and provide an attractive
trim. The splice posts support the
wall.
1 Position a rear splice post at the
center of the rear wall and fasten
using bolts and nuts into rear wall
angle and screws into rear floor
frame.
Hint: Measure or count holes to de-
termine if post is centered on rear.
2 Fasten side splice posts to the
sides of building in the same manner.
Angled end of post must be on top.
3 Fasten the top of the door jambs
to the door track with 2 screws. Do
the same for the bottom into frame.
Notched edge faces toward center of
building.
●●
●●
● 8718 Rear Splice Post (1)
●●
●●
● 8734 Side Splice Post (2)
●●
●●
● 8717 Door Jamb (2)
● Parts Needed For ●
Splice Post/Door Jamb
Step 7
M20
20
ANGLED END OF
SPLICE POST MUST
BE ON TOP
1
STEP
STEP
3
NOTCHED EDGE
MUST FACE CENTER
OF BUILDING
FRONT
FRONT
Washer
8717
8734
8718
8734
STEP
2
8717
