Installation Instructions

Each screw in the wall requires a
washer.
1 Slide side siding (5 board) into
channels of corner and splice posts,
flat edge upward, slotted edge down
resting on floor frame. Always follow
this pattern. Fasten lower edge and
tab of stud to floor frame using screws.
Fasten center to stud with screws.
Do not fasten top edge yet.
2 Install side siding (3 board) as
before. Note how the slot in lower
edge must overlap flat edge of last
siding. Fasten both siding panels to
stud at this overlap.
3 Install side siding (5 board) to the
top as before. Remove and re-use
screw in angle to fasten top siding.
4 From inside building, fasten siding
to corner posts and splice posts us-
ing screws.
5 Install rear siding and front sid-
ing as before. Note that the front
siding is only fastened from inside.
NOTE
Be careful to install the correct
panel in each position as shown.
The floor frame must be square
and level or holes will not align.
●●
●●
● 8735 Side Siding (5 board) (8)
●●
●●
● 5320 Side Siding (3 board) (4)
●●
●●
● 8736 Rear Siding (5 board) (4)
●●
●●
● 5307 Rear Siding (3 board) (2)
●●
●●
● 8737 Front Siding (5 board) (4)
●●
●●
● 5291 Front Siding (3 board) (2)
● Parts Needed For ●
Side/Rear/Front Siding
Step 9
M22
22
STEP
2
STEP
3
Washer
(5 board)
STEP
STEP
4
STEP
5
1
(5 board)
(5 board)
(5 board)
(3 board)
(3 board)
CORRECT INCORRECT
