Installation Instructions

26
Step 13
M26
● Parts Needed For ●
Right Roof Panel
●●
●●
● 7952 Right Roof Panel (1)
Installing the roof panels is best done
with a step ladder. Begin installing
roof panels at the back right corner of
the building. Each screw and bolt in
the roof requires a washer.
NOTE
Measure the building diagonally
again and make adjustments to
make sure the building is square
and level. This will make the roof
panels fit better, and holes will
align.
NOTE
If a Roof Beef-Up Kit was
purchased, assemble prior to
attaching the roof panels.
1 Locate all the roof panels by their
numbers and place them on the
ground alongside the building in their
proper positions.
2 Position the right roof panel at the
back right corner and fasten to the
gable and roof beams using screws
and bolts and nuts as shown. Do not
fasten the lower end of the panels to
the side wall angles at this time.
Hint: Follow the fastener sequence
shown, for proper alignment.
STEP
2
STEP
1
FRONT
FRONT
7
5
3
1
4
6
2
8
7953
7954
7952
7952
7953
7954
7954
7954
7952 Right Roof Panel
Washer
Bolt
Gable
Nut
1
8 - 11
16 - 19
5
2
3
4
6
12 - 15
7
