Sensorless Vector Control Actual Size (SJ100-004NFE, 004NFU) All Rights Reserved,Copyright ©2002,Hitachi,Ltd. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.
The small inverter with the power of a big one Precise torque regulation using senseless vector control! The torque calculation software (sensorless vector control) developed by Hitachi ensures accurate torque control throughout the entire frequency range, even with general purpose motors. • High starting torque of 200%or more (3.7kW~ : 180% or more) • 100% continuous operating torque within a 1:10 speed range (6 to 60 Hz/5 to 50 Hz) without motor de-rating. (3.
CONTENTS W Features P1~4 W Standard Specifications P5 W Dimensional Drawings P6~7 W Operation W Function List W Terminal Functions P13 W Protective Functions P14 W Connection Diagram P15 W Applicable Wiring Apparatus and Options P16 W For Correct Operation P8 P9~12 P17~18 Advanced Functions Condensed in One Unit X Auto tuning to set motor constants X Second motor setting (Provision to set second motor constants) X PID control provided as standard X 16 –stage multispeed operation
Compact, Powerful, Intelligent and Easy to Use Perfect matching to Constant torque load The powerful and intelligent SJ100 inverter series solves your applications requirements for high torque at low speeds. [Dynamic braking circuit incorporated as standard] X CONVEYOR X TRUCK X EXTRUDER X MIXER X LIFT etc. Simple Operation By keypad or external input signals The SJ100 can be started by pressing the RUN button or receiving an external signal through the terminal.
Network-Compatible World Standard Machine Expands Global Business The SJ100 Series of world standard machines provide global performance. X European low–voltage directive compliant, EMC directive compliant (with dedicated noise filter) X UL, c–UL standards X C–Tick (Australian EMC requirment, with dedicated noise filter) The line -up includes models compatible with DeviceNet. Model Type List SJ100 - 004 N F E Series name Applicable motor rating 002 0.2kW 075 7.
Standard Specifications Item 200 V Class Model (S J100-) Protective structure: Applicable motor(kW) 0.2 Rated capacity(kVA)(240V/460V) 0.6 0.55 0.75 1.1 1.5 2.2 3.7 5.5 7.5 1.2 1.6 2.0 3.3 4.5 7.2 9.9 13.3 1-phase : 200~240V+5%/-10%, 50/60Hz +/-5% 3-phase : 200~230V+10%/-10%,50/60Hz+/-5% (037~075LFU :3-phase only) 3-phase 200~240V (corresponding to input voltage) Rated input voltage Rated output voltage Rated output current (A) Control method 1.6 0.4 1.0 2.6 3.0 4.0 5.0 0.75 1.9 1.5 3.0 2.2 4.
Dimensional Drawings V SJ100-002NFE, 004NFE, 005NFE V SJ100-007NFE, 011NFE, 004HFE 002NFU, 004NFU 007NFU, 004HFU model 002NFE 002NFU 004NFE 005NFE 004NFU V SJ100- 015NFE, 015NFU D 93 107 V SJ100-007HFE, 015HFE, 022HFE 007HFU, 015HFU, 022HFU V SJ100-022NFE, 030HFE, 040HFE 022NFU, 037LFU, 040HFU ✽ 007HFE , 007HFU with out FAN VSJ100-055LFU,055HFE,055HFU, 075HFE,075HFU V SJ100- 075LFU 6 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.
Dimensional Drawings V FFL100-SB3, LB3 V FFL100-HB32 V FFL100-SB5, HB6 V FFL100-SB11, HB11, HB17 Noise filter Inverter model Input Power Source Inverter model SJ100-002NF 004NF * * SJ100-005NFE 007NF * SJ100-011NFE 015NF 022NF* * 1-phase 200V class 3-phase 200V class 1-phase 200V class 3-phase 200V class FFL100-SB3 FFL100-LB3 FFL100-SB5 FFL100-HB6 1-phase 200V class FFL100-SB11 3-phase 200V class FFL100-HB11 SJ100-037LFU 3-phase 200V class FFL100-HB17 SJ100-055LFU 075LFU 3-phase 200V clas
Operation The SJ100 Series can be easily operated with the digital operator panel equipped as standard in the main unit. For remote operation, the remote operator unit is available as an option. Power lamp Monitor section (LED) Displays the monitored frequency, motor current, motor rpm, or alarm condition. Indicates ON/OFF of the control circuit power supply. Monitor lamp Monitor lamp Indicates the monitor item. Indicates the monitor item.
Function List ‘‘xxE type’’ and ‘‘xxU type’’ in the tables below refer to the model types for Europe and North America, respectively.
Code V/F Characteristics DC Braking Upper/Lower Limiter,Jump Frequency PID Control A41 A241 A42 A242 A43 A243 Function Torque boost mode selection 2nd setting torque boost mode selection Manual torque boost setting 2nd setting manual torque boost setting Boost frequency setting 2nd setting boost frequency setting A44 Control method setting A244 2nd setting Control method setting A45 A51 A52 A53 A54 A55 A61 A62 A63 A64 A65 A66 A67 A68 A71 A72 A73 A74 A75 A76 Output voltage gain setting DC braking
B Group: Fine Tuning Functions Code Instantaneous Stop Restart Function b213 Setting Range Trip/0Hz start Selection of restart mode /interrupt start /interrupt stop Allowable instantaneous power failure time setting 0.3 ~ 25 s Time and delay enforced before motor restarts 0.
Code Intelligent Output Terminal Setting Intelligent Output Terminal Active State C21 Output terminal 1 setting C22 Output terminal 2 setting C23 FM terminal setting Setting Range Code 00 01 02 03 04 05 Initial Setting Function RUN (Running signal) FA1 (Frequency arrival signal:command arrival) FA2 (Frequency arrival signal:setting or more) OL (Overload advance notice signal) OD (Output deviation for PID control) AL (Alarm signal) FA1 RUN A-F (Analog output frequency monitor) A (Analog output
Terminal Functions [Main Circuit Terminal] [Control Circuit Terminal] Terminal Screw Diameter 007~022NFE 055~075LFU 002~005NFE 007~022NFU 037LFU 055~075HFE 002~004NFU 004~040HFE 055~075HFU 004~040HFU Main circuit terminal Main circuit terminal Control circuit terminal Front case (right open) M3.
Protective Functions Digital operator Description Name When the motor is restrained or suddenly reduced in speed, a large current is charged to the inverter, causing a fault. When the inverter detects 205% peak current for the rated current of the inverter,Over current is occurred. Overcurrent protection Remote operator /copy unit ERR1 **** Constant speed OC.Drive Deceleration OC.Decel Acceleration OC.Accel Others Over.
Connection Diagram Inverter Main power supply 3-phase 200~230V 50/60 Hz L1 T1 L2 T2 L3 T3 Motor DCL (DC reactor) (option) +1 P24 1 2 3 4 + L L RB L - Dynamic braking resistor (option) Dynamic braking unit (option) AL0 L 5V AL1 5 Alarm relay output AL2 6 L 11 L RY FM L Frequency setting device 1kΩ~2kΩ (0.3W or more is recommended) H 12 DC10V RY DC24V CM2 O *1: Note that the common terminal differs depending on the terminal name.
Applicable Wiring Apparatus and Options Standard Apparatus Wiring Motor Output (kW) (Power supply) Fuse Inverter model Power lines 0.2 SJ100-002NFE/NFU 0.4 SJ100-004NFE/NFU 0.55 SJ100-005NFE 0.75 SJ100-007NFE/NFU Signal lines Applicable equipment Fuse(class J) rated 600V AWG16/1.3mm2 10A AWG14/2.1mm2 15A 1.1 SJ100-011NFE 1.5 SJ100-015NFE/NFU AWG12/3.3mm2 25A(single ph.) 15A(three ph.) 2.2 SJ100-022NFE/NFU AWG10/5.3mm2 30A(single ph.) 20A(three ph.) 3.7 SJ100-037LFU 5.
For Correct Operation Application to Motors [Application to general-purpose motors] Operating frequency The overspeed endurance of a general-purpose motor is 120% of the rated speed for 2 minutes (JIS C4004). For operation at higher than 60 Hz, it is required to examine the allowable torque of the motor, useful life of bearings, noise, vibration, etc. In this case, be sure to consult the motor manufacturer as the maximum allowable rpm differs depending on the motor capacity, etc.
[Main power supply] In the cases below involving a general-purpose inverter, a large peak current flows on the main power supply side, and is able to destroy the converter module. Where such situations are foreseen or the connected equipment must be highly reliable, install an AC reactor between the power supply and the inverter. Also, where influence of indirect lightning strike is possible, install a lightning conductor. (A) The unbalance factor of the power supply is 3% or higher.
Printed in Japan (H) SM-E229R 0602 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.
