Specifications

Code Function Setting Range Initial Setting
A61 Frequency upper limiter setting 0.0, 0.5 ~ 360(Disable when 0.0) Hz 0.0 Hz
A62 Frequency lower limiter setting
0.0, 0.5 ~ 360(Disable when 0.0) Hz 0.0 Hz
A63 Jump frequency setting 1 0.0 ~ 360 Hz 0.0 Hz
A64 Jump frequency width setting 1 0 ~ 10 Hz 0.5 Hz
A65 Jump frequency setting 2 0 ~ 360 Hz 0 Hz
A66 Jump frequency width setting 2 0 ~ 10 Hz 0.5 Hz
A67 Jump frequency setting 3 0 ~ 360 Hz 0 Hz
A68 Jump frequency width setting 3 0 ~ 10 Hz 0.5 Hz
A71 Enable PID function ON/OFF OFF
A72 P gain setting 0.2 ~ 5 times 1.0
A73 I gain setting 0.0 ~ 150 s 1.0 s
A74 D gain setting 0.0 ~ 100 s 0.0 s
A75 PV scale conversion 0.01 ~ 99.99 1.00
A76 PV source setting Current/Voltage Current
A81 AVR function selection
ON/OFF/OFF at xxE type:OFF at decel.
deceleration xxU type:ON
A82 AVR voltage selection
200/220/230/240 xxE type:230/400
380/400/415/440/460 xxU type:230/460
A92 Second acceleration time setting 0.1 ~ 3000 s 15.0 s
A292 2nd setting second acceleration time setting 0.1 ~ 3000 s 15.0 s
A93 Second deceleration time setting 0.1 ~ 3000 s 15.0 s
A293 2nd setting second deceleration time setting 0.1 ~ 3000 s 15.0 s
A94
Second acceleration/deceleration Terminal /switching
Terminal
switching method frequency
A294
2nd setting second acceleration/deceleration Terminal /switching
Terminal
switching method frequency
A95 Acceleration switching frequency 0 ~ 360 Hz 0 Hz
A295 2nd setting acceleration switching frequency 0 ~ 360 Hz 0 Hz
A96 Deceleration switching frequency 0 ~ 360 Hz 0 Hz
A296 2nd setting deceleration switching frequency 0 ~ 360 Hz 0 Hz
A97 Acceleration pattern selection Linear/S-curve Linear
A98 Deceleration pattern selection Linear/S-curve Linear
PID
Control
AVR
2nd
Acceleration/
Deceleration
Function
Upper/Lower
Limiter,Jump
Frequency
A41 Torque boost mode selection Manual/Auto Manual
A241 2nd setting torque boost mode selection Manual/Auto Manual
A42 Manual torque boost setting 0 ~ 99 11
A242 2nd setting manual torque boost setting 0 ~ 99 11
A43 Boost frequency setting 0.0 ~ 50.0% 10%
A243 2nd setting boost frequency setting 0.0 ~ 50.0% 10%
A44 Control method setting Sensorless vector
A244 2nd setting Control method setting Sensorless vector
A45 Output voltage gain setting 50 ~ 100% 100%
A51 DC braking enable ON/OFF OFF
A52 DC braking frequency setting 0.5 ~ 10Hz 0.5Hz
A53 DC braking output delay time setting 0.0 ~ 5 s 0.0 s
A54 DC braking force setting 0 ~ 100% 0%
A55 DC braking time setting 0.0 ~ 60 s 0.0 s
V/F
Character-
istics
DC
Braking
•Constant torque
•Reduced torque
•Sensorless vector
(
*
)
•Constant torque
•Reduced torque
•Sensorless vector
(
*
)
10
(
*
) Sensorless vector selected, set carrier frequency more than 2.1kHz by b83
