Line/Instrument inputs
Line Input Impedance 20k ohms symetric, 10k ohms asymetric
Instrument Input Impedance 1.1M ohms asymetric
Frequency Response 20Hz/20kHz < +/- 0.08dB
Instrument Max Input Level +18dBu
Max Input Level +24dBu
Microphone Preamps
Input Impedance 4k ohms
Equivalent Input Noise (EIN) @ 72dB gain <-129.3dBu (A-weighted)
Frequency Response 20Hz/20kHz < +/- 0.08dB
Gain Range 3dB to 72dB
Inserts
Output Impedance <35 ohms
Input Impedance 10k ohms asymetric
Max Output Level +18dBu
Nominal Input Level +18dBu
Line Input to Digital
THD+N -101dB (A-weighted)
Dynamic Range 106dB (A-weighted)
