Asanté IntraCore 3500 Series
Failure to observe these limits may cause damage to the switch and
void the warranty.
Avoid direct sunlight, heat sources, or areas with high levels
of
electromagnetic interference.
2.5 Cooling and Airflow
The switch uses internal fans for air cooling. Do
not restrict air flow by covering or obstructing
air vents on the sides of the switch.
2.6 Installation Overview
Follow these steps to install the switch:
1. Open the box and check the contents. See Chapter 1.1 Package
Contents for a complete list of the items included with your purchase.
2. Install the IntraCore switch chassis in an equipment rack or wall
rack, or prepare it for desktop placement.
3. Connect the power supply.
4. Connect network devices to the switch.
5. Refer to the user’s manual on the CD-ROM for configuring the
switch for management capabilities.
2.7 Chassis Installation/Placement
The switch can be installed in a standard 19-inch equipment rack. It
can also be placed on a stable horizontal surface.
Note: The equipment rack or desk on which you install the switch
must be secure and stable. Equipment racks must be fastened to
the floor; desks must be resting on a flat, stable surface. Refer to
Chapter 2.4 for the environmental requirements of the switch.
2.7.1 Installation in an Equipment Rack
To install the unit in an equipment rack, use the following
procedure:
Important! Before continuing, disconnect all cables from the
switch.
