Configuring IPX Routing

Configuring IPX routing connections

Pipeline User’s Guide Preliminary January 30, 1998 4-31

To configure the site B Ascend unit:

Assign the Ascend unit a name if it does not already have one.

To assign the Pipeline a name, open the System profile and specify the name

in the Name parameter. For example:

Name=SITEBGW

Open the Connection profile for site A.

Set up the Connection profile like this:

Station=SITEAGW

Active=Yes

Encaps=MPP

Dial #=555-1213

Route IP=No

Route IPX=Yes

Bridge=No

Dial brdcast=N/A

Encaps options...

Send Auth=CHAP

Recv PW=*SECURE*

Send PW=*SECURE*

IPX options...

IPX RIP=Both

IPX SAP=Both

NetWare t/o=30

Close and save the profile.
