Defining Filters and Firewalls
Working with predefined call filters
Pipeline User’s Guide Preliminary January 30, 1998 6-27
these two pairs, a packet has to meet the criteria defined in both filters to be
considered a match. The last Output filter tells the Pipeline to allow all other
outbound packets to reset the idle timer or initiate a call.
In filter 01...Generic...Forward=No
In filter 01...Generic...Offset=0
In filter 01...Generic...Length=0
In filter 01...Generic...Mask=000000000000000000
In filter 01...Generic...Value=0000000000000000
In filter 01...Generic...Compare=Equals
In filter 01...Generic...More=No
Out filter 01...Generic...Forward=No
Out filter 01...Generic...Offset=14
Out filter 01...Generic...Length=8
Out filter 01...Generic...Mask=ffffff000000ffff
Out filter 01...Generic...Value=aaaa03000000809b
Out filter 01...Generic...Compare=Equals
Out filter 01...Generic...More=Yes
Out filter 02...Generic...Forward=No
Out filter 02...Generic...Offset=32
Out filter 02...Generic...Length=3
Out filter 02...Generic...Mask=ffffff0000000000
Out filter 02...Generic...Value=0404040000000000
Out filter 02...Generic...Compare=Equals
Out filter 02...Generic...More=No
Out filter 03...Generic...Forward=No
Out filter 03...Generic...Offset=12
Out filter 03...Generic...Length=2
Out filter 03...Generic...Mask=ffff000000000000
Out filter 03...Generic...Value=809b000000000000
Out filter 03...Generic...Compare=Equals
Out filter 03...Generic...More=Yes
Out filter 04...Generic...Forward=No
Out filter 04...Generic...Offset=24
