Defining Filters and Firewalls
Display unwanted dial-out packets
Pipeline User’s Guide Preliminary January 30, 1998 6-33
Example 5
In this example, the phone number dialed on receipt of this packet is 92233002.
The type OLD-STYLE-PADDED means that the packet has a 14-byte MAC
header + datagram.
The packet contents provide the following information:
chksum ff:ff
packet len 00:22 /* 34 */
Transport Control 00 /* 0 */
packet type 11 /* 17 NCP Packet */
dest network 00:00:00:00
dest Node ff:ff:ff:ff:ff:ff
dest Socket 04:52 /* SAP */
source network 00:00:00:00:00
source Node 00:a0:24:be:d5:84 /*physical addr of Node*/
Source Socket 40:09 /*4000h-7fffh Dynamic socket*/
Sap operation 00:03 /* Get Nearest Server Request */
Sap Service Type 0:04 /* File Server */
Date: 01/01/1990. Time: 02:40:35
Cause an attempt to place call to 92233002
WD_DIALOUT_DISP: chunk 260126 type OLD-STYLE-PADDED.
: 60 octets @ 2AE950
[0000]: 00 80 5f 74 93 d5 00 80 c7 2f 32 4c 00 2a ff ff
[0010]: 00 29 00 11 30 6c 6b 00 00 00 00 00 00 01 04 51
[0020]: 82 c1 b6 bf 00 80 c7 2f 32 4c 40 03 22 22 3f 03
[0030]: 01 00 16 00 02 15 01 ff ff ff ff ff
